The Kubota M8560 is a modern utility tractor produced between 2013 and 2016 as part of Kubota’s M60 Series. It is designed to deliver high efficiency, operator comfort, and strong performance for a wide range of agricultural applications.
Powered by a 3.8L 4-cylinder diesel engine producing 85.5 HP, the M8560 is ideal for fieldwork, loader operations, and transport tasks. It builds on the reliability of the M8540 while offering improved comfort and upgraded features.
Key Features
- Powerful and efficient Kubota 3.8L diesel engine
- Advanced power shuttle transmission options
- Comfortable cab with air-conditioning and optional air-ride seat
- Strong hydraulic system for heavy-duty work
- Multiple configurations for different farming needs
Engine Specifications
| Item | Details |
|---|---|
| Engine Model | Kubota Diesel Engine |
| Displacement | 3.8L |
| Cylinders | 4-cylinder |
| Fuel Type | Diesel |
| Engine Power (Net) | 85.5 hp (63.8 kW) |
This engine provides a strong balance of power and fuel efficiency, suitable for continuous agricultural operations.
Transmission
| Type | Details |
|---|---|
| Power Shuttle | 8-speed |
| Advanced Transmission | 12-speed |
The power shuttle system allows smooth forward/reverse changes, improving efficiency in loader work and tight field operations.
Power Output
| Item | Power |
|---|---|
| Engine (Net) | 85.5 hp |
| PTO (claimed) | 76 hp |
Mechanical Features
| Item | Details |
|---|---|
| Drive Type | 2WD / 4WD |
| Steering | Hydrostatic power steering |
| Brakes | Hydraulic wet disc |
| ROPS | Foldable ROPS (Cab optional) |
| Cab Features | A/C, air-ride seat (optional), audio system |
Hydraulics
| Item | Details |
|---|---|
| Valves | 1 to 3 |
| Pump Flow (ROPS) | 15.9 gpm (60.2 L/min) |
| Pump Flow (Cab) | 17.0 gpm (64.3 L/min) |
The hydraulic system supports various implements, ensuring versatility and high productivity.
Capacity
| Item | Capacity |
|---|---|
| Fuel Tank (ROPS) | 23.8 gal (90.1 L) |
| Fuel Tank (Cab) | 29.1 gal (110.1 L) |
PTO (Power Take-Off)
| Item | Details |
|---|---|
| Type | Independent |
| Clutch | Electro-hydraulic |
| PTO Options | 540 / 540E / 540-1000 |
Hitch & Lifting Capacity
| Item | Details |
|---|---|
| Hitch Type | Category II |
| Control | Position control & draft sensing |
| Lift Capacity (24″) | 2,100 kg (Optional: 3,299 kg) |
| Rear Arms | Telescopic lower link ends |
Dimensions & Tires
| Item | Details |
|---|---|
| Wheelbase (ROPS) | 228 cm |
| Wheelbase (Cab) | 225 cm |
| Weight | 2,450 – 3,030 kg |
| Front Tire | 7.50-18 |
| Rear Tire (2WD) | 16.9-30 |
Attachments
- Front-end loader
- Various agricultural implements
Variants
| Model | Description |
|---|---|
| M8560HF | 2WD ROPS |
| M8560HFC | 2WD Cab |
| M8560HD | 4WD ROPS |
| M8560HDC | 4WD Cab |
| M8560HD12 | 4WD 12-speed |
| M8560HDC12 | 4WD Cab 12-speed |
Electrical System
| Item | Details |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Amps | 45A (ROPS) / 60A (Cab) |
| Optional Output | 100A |
| Battery | 12V |
Why Choose Kubota M8560?
The Kubota M8560 is a preferred choice for farmers worldwide because of:
- Reliable and fuel-efficient engine
- Smooth transmission with power shuttle
- Comfortable working environment with modern cab features
- Strong hydraulics for heavy implements
- Proven durability in demanding agricultural conditions
This tractor is ideal for those seeking a modern, powerful, and comfortable Japanese tractor for professional farming operations.
The Kubota M8560 continues to deliver excellent performance and reliability, making it a valuable asset for farmers across Africa, the Caribbean, and beyond.
