Kubota KL230 Compact Utility Tractor
Overview
The Kubota KL230 is a versatile compact utility tractor designed for light-to-medium agricultural work, orchard operations, and property maintenance.
Manufactured by Kubota between 2006 and 2007, the KL230 is part of the durable Kubota KL Series. It offers higher output than the KL210 while maintaining compact size, easy handling, and excellent fuel efficiency.
Key Information
| Item | Details |
|---|---|
| Manufacturer | Kubota |
| Model | KL230 |
| Series | KL Series |
| Production Years | 2006 – 2007 |
| Tractor Type | Compact Utility Tractor |
| Drive System | Four-Wheel Drive (4WD) |
| Steering | Power Steering |
| Brakes | Mechanical Wet Disc |
| ROPS | Two-Post ROPS |
| Cab | Optional |
Series Map
| Model | Engine Output |
|---|---|
| KL23 | 1999 – 2005 |
| KL210 | 15.4 kW |
| KL230 | 16.9 kW |
| KL250 | 18.4 kW |
| KL245 | 2008 – 2009 |
Variants
| Variant | Description |
|---|---|
| KL230 | Standard version |
| KL230H | High-speed version |
Engine
The KL230 is powered by a reliable Kubota diesel engine that delivers smooth torque and dependable performance for daily use.
| Specification | Details |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | Diesel |
| Cylinders | 3 |
| Displacement | 1.5 L |
| Rated Engine Power | 22.7 hp (16.9 kW) |
| Fuel Tank Capacity | 7.1 gal (26.9 L) |
| Electrical System | 12 V |
| Ground | Negative |
Transmission
Multiple transmission options allow flexibility for field work and transport.
| Transmission Type | Details |
|---|---|
| Mechanical Transmission | 16-Speed |
| Mechanical Transmission | 24-Speed |
Power & PTO
Stable PTO output supports a wide range of compact tractor implements.
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
| Rear PTO Type | 540 rpm (1.375 in) |
| Engine RPM @ PTO | 2500 rpm |
| PTO Output Speeds | 542 / 764 / 947 / 1263 rpm |
| PTO Reverse | −947 rpm |
Dimensions & Tires
Compact proportions with improved rear traction for field operations.
| Specification | Measurement |
|---|---|
| Wheelbase (ROPS) | 61 in (154 cm) |
| Wheelbase (Cab) | 63 in (160 cm) |
| Operating Weight | 2535 – 2954 lbs |
| Front Tire Size | 6-14 |
| Rear Tire Size | 9.5-24 |
Photos
Currently, no public photos of the Kubota KL230 are available.
When units are in stock, EVERY FARM TRACTOR can provide actual machine photos upon request.
Why Choose the Kubota KL230?
-
Balanced 22.7 hp diesel performance
-
Available high-speed variant (KL230H)
-
Compact size with improved rear traction
-
Ideal for small farms, orchards, and maintenance work
