Kubota GB175 Tractor Specifications and Model Guide
The Kubota GB175 is a sub-compact utility tractor produced from 2004 to 2006 as part of the popular Kubota GB Series.
With a 1.0L three-cylinder diesel engine, four-wheel drive and compact dimensions, it is designed for small farms, orchards, vineyards, vegetable fields and garden work where both power and agility are required.
This page explains the key specifications of the Kubota GB175, including engine displacement, transmission, PTO, and dimensions, so that overseas buyers can easily understand this Japanese used tractor.
Overview
| Item | Details |
|---|---|
| Model | Kubota GB175 |
| Tractor type | Sub-Compact Utility tractor |
| Series | Kubota GB Series |
| Production years | 2004 – 2006 |
| Manufacturer | Kubota Corporation (Japan) |
| Drive | 4WD (Four-wheel drive) |
| Steering | Manual steering (power steering optional) |
| Brakes | Mechanical wet disc brakes |
| ROPS | Two-post ROPS |
GB Series model map (segment)
| Series map | Engine power (approx.) |
|---|---|
| GB155 | 11.0 kW |
| GB175 | 12.5 kW |
| GB170 (earlier model, 2002–2003) | 12.5 kW |
The GB175 is the later 1.0L model, offering the same power class as the GB170 but in the new production period, combining compact size, strong PTO power and easy handling.
Engine
The Kubota GB175 is powered by a 1.0L three-cylinder Kubota diesel engine.
This power unit is known for its good low-end torque, low fuel consumption and long service life, which is ideal for everyday farm work.
| Item | Details |
|---|---|
| Engine manufacturer | Kubota |
| Engine type | 4-stroke, liquid-cooled diesel |
| Cylinders | 3 cylinders |
| Displacement | 1.0 L class (approx. 1000 cc) |
| Engine power | 16.8 hp (12.5 kW) |
| Aspiration | Naturally aspirated |
| Fuel type | Diesel |
| Fuel tank capacity | 3.4 gal (12.9 L) |
| Cooling system | Liquid-cooled |
| Starting system | Electric start |
Thanks to the 1.0L displacement, the GB175 has more torque and power than the smaller 0.7L and 0.9L GB models, making it suitable for heavier rotary tillage, mowing and light transport work.
Transmission
The GB175 is equipped with a 6-speed gear transmission, designed to be simple, durable and easy to service.
| Item | Details |
|---|---|
| Transmission type | Gear drive |
| Number of gears | 6-speed gear (forward/reverse combination) |
| Clutch | Dry single-plate (typical for this class) |
| Drive system | 4WD (Four-wheel drive) |
The mechanical gear transmission provides:
-
Reliable power transfer to the wheels
-
Suitable speeds for tillage, mowing and slow manoeuvring
-
Easy maintenance in markets where advanced electronics are difficult to repair
Optional power steering further improves comfort when working long hours or using front-mounted implements.
PTO (Power Take-Off) and Hitch
The Kubota GB175 is fitted with a rear PTO and a Category 0 three-point hitch, allowing it to operate many small and medium-sized implements.
Rear PTO
| Item | Details |
|---|---|
| Rear PTO type | 540 / 1000 rpm |
| PTO shaft size | 1.375″ |
3-Point Hitch
| Item | Details |
|---|---|
| Rear hitch type | Category 0 |
| Hitch control | Position control |
With position control, the operator can set and maintain the implement height precisely, which is essential for:
-
Consistent tillage depth
-
Clean and even mowing
-
Accurate bed forming and ridging in vegetable fields
Dimensions & Tires
The GB175 keeps the same compact frame as many GB models, making it easy to use in narrow rows, small plots and tight farmyards.
| Item | Details |
|---|---|
| Wheelbase | 50 in (127 cm) |
| Weight | 1,246 lbs (565 kg) |
| Front tire | 5.00-12 |
| Rear tire | 8-18 |
This combination of short wheelbase, moderate weight and 4WD gives the GB175:
-
Good stability on slopes and uneven ground
-
Low to moderate soil compaction, suitable for vegetable and orchard work
-
Easy loading into shipping containers for export from Japan
Electrical System
| Item | Details |
|---|---|
| Ground | Electric (negative ground) |
| Battery | 12-volt battery |
The simple 12V electrical system supports engine starting, lights and instruments, and replacement batteries are widely available in most countries.
Photos
Currently, no official Kubota GB175 photos are registered in the original spec data.
On EVERY FARM TRACTOR’s website, we usually provide:
-
Front, side and rear exterior photos
-
Operator’s area (seat, steering wheel, levers, pedals)
-
Engine compartment and underbody
-
Detailed shots of tires, PTO shaft and three-point hitch
These photos allow overseas buyers to check the actual condition of the used tractor, including rust, oil leaks, tire wear, paint condition and any modifications.
Kubota GB175 – Typical Applications
With its 1.0L diesel engine and 16.8HP output, the Kubota GB175 is a strong yet compact tractor ideal for:
-
Small and medium family farms
-
Commercial vegetable farms and greenhouses
-
Orchards and vineyards needing higher PTO power in narrow rows
-
Lawn and garden maintenance, mowing and light landscaping
-
Light trailer work and internal farm transport
For overseas buyers, the GB175 offers:
-
Reliable Japanese build quality
-
Extra power compared to smaller GB models (GB150, GB155)
-
Compact dimensions and 4WD for tight and uneven fields
-
Simple mechanical systems that are easy to service with basic tools
EVERY FARM TRACTOR can support customers by:
-
Sourcing good-condition used Kubota GB175 units from Japanese auctions and local farmers
-
Providing detailed inspection reports with many photos (and videos on request)
-
Arranging export from Japan using container or RORO shipping, according to destination, budget and total shipment volume
