Kubota GB180 Tractor Specifications and Model Guide
The Kubota GB180 is a sub-compact utility tractor produced from 2002 to 2003 as part of the Kubota GB Series.
With its 1.0L three-cylinder diesel engine, four-wheel drive, power steering and multi-speed PTO, the GB180 is designed for small farms, orchards, vineyards, vegetable fields and landscaping work where both power and manoeuvrability are important.
This page presents the main specifications of the Kubota GB180, including engine displacement, transmission options, PTO details, and dimensions, so overseas buyers can easily understand this Japanese used tractor.
Overview
| Item | Details |
|---|---|
| Model | Kubota GB180 |
| Tractor type | Sub-Compact Utility tractor |
| Series | Kubota GB Series |
| Production years | 2002 – 2003 |
| Manufacturer | Kubota Corporation (Japan) |
| Drive | 4WD (Four-wheel drive) |
| Steering | Power steering |
| Brakes | Mechanical wet disc brakes |
| ROPS | Two-post ROPS |
GB Series model map (segment)
| Model | Engine power (approx.) |
|---|---|
| GB160 | 11.8 kW |
| GB180 | 13.2 kW |
| GB200 | 14.7 kW |
The GB180 sits in the middle of this power band, offering more power than the GB160 while staying compact and easy to handle.
Engine
The Kubota GB180 is powered by a 1.0L three-cylinder Kubota diesel engine.
This engine provides strong low-speed torque and good fuel economy, making it suitable for intensive daily work on small and medium-sized farms.
| Item | Details |
|---|---|
| Engine manufacturer | Kubota |
| Engine type | 4-stroke, liquid-cooled diesel |
| Cylinders | 3 cylinders |
| Displacement | 1.0 L class (approx. 1000 cc) |
| Engine power | 17.7 hp (13.2 kW) |
| Aspiration | Naturally aspirated |
| Fuel type | Diesel |
| Fuel tank capacity | 5.3 gal (20.1 L) |
| Cooling system | Liquid-cooled |
| Starting system | Electric start |
The combination of 1.0L displacement and multi-speed PTO makes the GB180 a good match for rotary tillers, mowers, ridgers and other PTO-driven tools.
Transmission
The GB180 offers two transmission choices, including a standard gear transmission and a more sophisticated Glideshift version.
Variants
| Variant | Description |
|---|---|
| GB180 | Standard model |
| GB180F | Glideshift transmission |
Transmissions
| Item | Details |
|---|---|
| Standard transmission | 9-speed gear |
| Optional transmission | 18-speed (Glideshift) |
| Drive system | 4WD (Four-wheel drive) |
| Steering | Power steering |
-
The 9-speed gear version is simple and robust, ideal for users who prefer basic, easy-to-service mechanics.
-
The 18-speed Glideshift version offers more gear steps, allowing the operator to fine-tune ground speed for different tasks and soil conditions.
PTO (Power Take-Off) and Hitch
The Kubota GB180 features a multi-speed rear PTO and a Category 0 three-point hitch, giving it excellent versatility for a wide range of small farm implements.
Rear PTO
| Item | Details |
|---|---|
| Rear PTO type | Multi-speed PTO |
| PTO speeds | 451 / 769 / 1207 (1.375″ shaft) |
Multiple PTO speeds help the operator match implement requirements with engine rpm, improving both work quality and fuel efficiency.
3-Point Hitch
| Item | Details |
|---|---|
| Rear hitch type | Category 0 |
| Hitch control | Position control |
With position control, the GB180 can hold the implement at a constant height, which is very important for:
-
Uniform tillage depth
-
Clean and even mowing
-
Accurate bed forming, ridging and soil finishing
Dimensions & Tires
The GB180 is slightly larger and heavier than some smaller GB models, but still compact enough for narrow fields, orchards and greenhouses.
| Item | Details |
|---|---|
| Wheelbase | 53.2 in (135 cm) |
| Weight | 1,532 – 1,587 lbs (approx. 695–720 kg) |
| Front tire | 6.00-12 |
| Rear tire | 8.3-22 |
This dimension and weight combination provides:
-
Good stability on slopes and uneven ground
-
Improved traction thanks to weight and 4WD
-
Relatively low soil compaction for vegetable and orchard use
Electrical System
| Item | Details |
|---|---|
| Ground | Electric (negative ground) |
| Battery | 12-volt battery |
The 12V electrical system powers the starter, lights and instruments, and replacement batteries are widely available around the world.
Photos
Currently, there are no official Kubota GB180 photos listed in the original spec source.
On EVERY FARM TRACTOR’s website, we usually provide:
-
Front, side and rear exterior photos
-
Photos of the operator’s station (seat, steering wheel, levers, pedals)
-
Engine room and underbody shots
-
Close-ups of tires, PTO shaft and three-point hitch
These detailed images help overseas buyers check the actual condition of each used tractor, including rust, oil leaks, tire wear, paint condition and any modifications.
Kubota GB180 – Typical Applications
With its 1.0L diesel engine, 17.7HP output, 4WD and power steering, the Kubota GB180 is a very versatile sub-compact tractor suitable for:
-
Small family farms and mixed cropping
-
Commercial vegetable farms and greenhouses
-
Orchards and vineyards with narrow rows but higher PTO power needs
-
Garden and landscape work, mowing and light loader tasks
-
Light trailer and transport work on the farm
For overseas buyers, the GB180 offers:
-
Reliable Japanese build quality
-
A strong 1.0L engine with good fuel economy
-
Power steering and multi-speed PTO for comfortable, efficient operation
-
A compact chassis that is easy to handle and easy to load into containers
