New Holland TV140 Overview
The New Holland TV140 is a high-performance bi-directional tractor designed for professional agricultural and municipal operations. Produced from 1998 to 2004, this unique model stands out for its reversible operator console and advanced versatility.
Manufactured in Winnipeg, Canada, and Fargo, USA, the TV140 is powered by a robust New Holland 7.5L 6-cylinder diesel engine, delivering 140 horsepower. This makes it ideal for heavy-duty applications such as mowing, snow removal, roadside maintenance, and large-scale farming.
One of its key features is the 180-degree rotating cab console, allowing the operator to work efficiently in both directions. Combined with its hydrostatic transmission and articulated steering, the TV140 offers exceptional control and maneuverability.
New Holland TV140 Quick Specifications
| Item | Details |
|---|---|
| Model | New Holland TV140 |
| Tractor Type | Bi-directional Tractor |
| Production Years | 1998 – 2004 |
| Manufacturer | New Holland |
| Built In | Canada / USA |
| Engine | New Holland 7.5L 6-cylinder diesel |
| Engine Power | 140 hp (104.4 kW) |
| PTO Power (claimed) | 105 hp (78.3 kW) |
| Transmission | Hydrostatic |
| Drive Type | 4WD |
| Fuel Tank Capacity | 55 gal (208.2 L) |
| Weight | 14,715 lbs (6,674 kg) |
| PTO Type | 540 / 1000 |
| Hitch Type | Category II |
| Steering | Hydrostatic articulated |
| Cab | Enclosed cab with heat & A/C |
Engine
The New Holland TV140 is equipped with a powerful 7.5-liter 6-cylinder diesel engine, engineered for heavy-duty performance and long operating hours.
With 140 horsepower, it delivers excellent torque and reliability for demanding applications. Therefore, it is suitable for both agricultural and industrial use.
Engine Specifications
| Item | Details |
|---|---|
| Engine Manufacturer | New Holland |
| Engine Type | Diesel |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Engine Power | 140 hp |
| Engine Power | 104.4 kW |
Transmission
The TV140 features a hydrostatic transmission, providing smooth and precise speed control without gear shifting.
This type of transmission is especially beneficial for tasks requiring frequent direction changes, such as mowing, loader work, and municipal operations.
Transmission Specifications
| Item | Details |
|---|---|
| Transmission Type | Hydrostatic |
| Drive | Infinite speed control |
Power and PTO
The TV140 offers both rear and front PTO systems, making it highly versatile for various attachments.
With 540 and 1000 PTO speeds, it can operate a wide range of implements efficiently.
PTO Specifications
| Item | Details |
|---|---|
| PTO Power (claimed) | 105 hp |
| PTO Power (tested) | 111.8 hp |
| Rear PTO | Independent |
| Front PTO | Independent |
| PTO Clutch | Electro-hydraulic wet disc |
| PTO Type | 540 / 1000 |
| Engine RPM (540) | 1890 rpm |
| Engine RPM (1000) | 2049 rpm |
Mechanical Features
The New Holland TV140 is designed with advanced mechanical systems to maximize performance and maneuverability.
Its articulated steering system allows tight turning, while 4WD ensures excellent traction in all conditions.
Mechanical Specifications
| Item | Details |
|---|---|
| Drive | Four-wheel drive |
| Final Drives | Planetary |
| Steering | Hydrostatic articulated |
| Brakes | Hydraulic wet disc |
| Cab | Enclosed with heat & A/C |
| Special Feature | 180° rotating operator console |
Hydraulics
The TV140 is equipped with a closed-center load-sensing hydraulic system, providing high efficiency and responsiveness.
This advanced system is ideal for operating demanding implements and attachments.
Hydraulic Specifications
| Item | Details |
|---|---|
| Hydraulic Type | Closed center load sensing |
| Capacity | 13.5 gal |
| Capacity | 51.1 L |
| Pressure | 3000 psi |
| Pressure | 206.8 bar |
| Pump Flow | 30 gpm |
| Pump Flow | 113.6 lpm |
Hitch and Lifting Capacity
The TV140 features both front and rear Category II hitches, significantly increasing its versatility.
Its high lifting capacity allows it to handle heavy implements with ease.
Hitch Specifications
| Item | Details |
|---|---|
| Rear Hitch Type | Category II |
| Rear Lift Capacity | 6500 lbs |
| Rear Lift Capacity | 2948 kg |
| Front Hitch Type | Category II |
| Front Lift Capacity | 5000 lbs |
| Front Lift Capacity | 2268 kg |
Dimensions and Weight
The TV140 is a large and heavy tractor designed for stability and performance in demanding environments.
Dimensions and Weight
| Item | Details |
|---|---|
| Wheelbase | 118.1 inches |
| Wheelbase | 299 cm |
| Weight | 14715 lbs |
| Weight | 6674 kg |
| Tire Size (Front/Rear) | 16.9-28 |
Capacity
The TV140 offers large fuel and hydraulic capacities, supporting long working hours without frequent refueling.
Capacity Specifications
| Item | Details |
|---|---|
| Fuel Tank | 55 gal |
| Fuel Tank | 208.2 L |
| Hydraulic System | 13.5 gal |
| Hydraulic System | 51.1 L |
Electrical System
The tractor uses a high-capacity electrical system suitable for heavy-duty operation.
Electrical Specifications
| Item | Details |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 100 amps |
| Batteries | 2 |
| Battery CCA | 950 |
| Battery Voltage | 12V |
Attachments
The New Holland TV140 supports various attachments, including front-end loaders and specialized equipment for municipal and agricultural use.
Available Attachments
| Item | Details |
|---|---|
| Attachment | Front-end loader |
Why Choose the New Holland TV140?
The New Holland TV140 is a unique and highly versatile tractor designed for professional use.
Key Benefits:
- Powerful 140 HP diesel engine
- Unique bi-directional operation
- Smooth hydrostatic transmission
- Advanced hydraulic system
- Dual front and rear PTO
- Ideal for municipal and large-scale farming
Final Thoughts
The New Holland TV140 stands out as one of the most innovative tractors in its class. Its bi-directional design, combined with strong power and advanced hydraulics, makes it a highly efficient machine for specialized tasks.
Even today, it remains a valuable option in the used equipment market, especially for buyers looking for versatility and high productivity.
