Overview
The Kubota L4300 is a dependable compact utility tractor from the Standard L Series, produced between 2001 and 2005. Designed as an economy version of the L4310, it offers excellent durability with a simple and reliable structure.
This model is widely used in global markets thanks to its ease of maintenance, solid performance, and cost-effectiveness.
| Item | Details |
|---|---|
| Model | Kubota L4300 |
| Production Years | 2001 – 2005 |
| Series | Standard L Series |
| Type | Compact Utility Tractor |
| Manufacturer | Kubota |
| Drive Options | 2WD / 4WD |
| Variants | L4300F (2WD), L4300DT (4WD) |
Engine
The Kubota L4300 is powered by a reliable Kubota 2.2L 4-cylinder diesel engine, designed for consistent performance and fuel efficiency.
| Item | Details |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | Diesel, 4-cylinder |
| Displacement | 2.2 L |
| Gross Power | 45.3 hp (33.8 kW) |
| PTO Power | 37.5 hp (28.0 kW) |
| Fuel Capacity | 31.0 L (8.2 gal) |
Key Features:
-
Proven Kubota diesel reliability
-
Efficient fuel consumption
-
Strong torque for agricultural work
Transmission
The L4300 features a simple and durable gear transmission, ideal for users who prefer mechanical reliability.
| Item | Details |
|---|---|
| Transmission Type | Sliding gear |
| Gears | 8-speed |
| Synchronization | Unsynchronized |
| Drive | 2WD / 4WD |
Highlights:
-
Strong and simple construction
-
Easy maintenance and repair
-
Suitable for rugged environments
Performance
| Item | Details |
|---|---|
| Engine Power | 45.3 hp |
| PTO Power | 37.5 hp |
Advantages:
-
Reliable power output for implements
-
Suitable for plowing, mowing, and transport
-
Stable performance under load
Hydraulics
The hydraulic system supports efficient operation of implements and attachments.
| Item | Details |
|---|---|
| Type | Open center |
| Pump Flow | 24.2 L/min |
| Total Flow | 39.4 L/min |
| Steering Flow | 14.8 L/min |
| Valves | 1 to 3 |
Hitch & PTO
| Item | Details |
|---|---|
| Hitch Type | Category I |
| Control | Position control (draft optional) |
| Rear Lift (ends) | 1,301 kg |
| Rear Lift (24″) | 1,047 kg |
| PTO Type | Independent |
| PTO Speed | 540 rpm |
Dimensions & Tires
| Item | Details |
|---|---|
| Wheelbase (2WD) | 181 cm |
| Wheelbase (4WD) | 180 cm |
| Weight | 1,290 – 1,350 kg |
| Front Tire | 7.5L-15 |
| Rear Tire (2WD) | 14.9-24 |
Mechanical Features
-
2WD or 4WD options
-
Helical gear final drives
-
Mechanical rear differential lock
-
Power steering for ease of operation
-
Wet disc brakes for durability
-
Two-post ROPS (no cab option)
Attachments
The Kubota L4300 is compatible with various attachments for multiple applications.
| Attachment | Description |
|---|---|
| Front-End Loader | Loading and lifting tasks |
| Backhoe | Digging and excavation |
Electrical System
| Item | Details |
|---|---|
| Ground | Negative |
| Battery | 12V |
| Battery CCA | 550 |
| Battery Capacity | 55 Ah |
Photos
Conclusion
The Kubota L4300 is a practical and reliable compact tractor designed for users who value simplicity, durability, and cost efficiency. Its strong diesel engine, straightforward transmission, and easy maintenance make it especially suitable for export markets and long-term use.
At EVERY FARM TRACTOR, we supply trusted Japanese used tractors like the Kubota L4300 to customers in over 100 countries. This model is highly regarded for its dependable performance and excellent value.
If you are looking for a robust 45HP tractor, the Kubota L4300 is a smart and proven choice for your agricultural operations.
