Kubota L3600 Tractor Specifications and Overview
The Kubota L3600 is a durable compact utility tractor from Kubota’s Grand L Series, produced between 1994 and 1999. Known for its reliability and strong performance, the L3600 was designed for agricultural work, landscaping, and property maintenance.
Powered by a Kubota 1.9-liter four-cylinder diesel engine, the tractor delivers 38.5 horsepower, providing excellent torque and efficiency for various field operations. The L3600 was available in both two-wheel drive (2WD) and four-wheel drive (4WD) configurations and offered synchronized shuttle and power shuttle transmissions.
With strong hydraulic capacity, a durable three-point hitch, and compatibility with multiple implements such as loaders, mowers, and backhoes, the Kubota L3600 remains a popular tractor for farmers and contractors worldwide.
EVERY FARM TRACTOR has been exporting reliable Japanese tractors like the Kubota L3600 to customers in over 100 countries since 2006, helping businesses and farms operate with trusted Japanese machinery.
Overview
| Item | Details |
|---|---|
| Model | Kubota L3600 |
| Production Years | 1994 – 1999 |
| Series | Grand L Series |
| Tractor Type | Compact Utility Tractor |
| Manufacturer | Kubota |
| Drive Type | 2WD or 4WD |
Series Map
| Model | Power | Production |
|---|---|---|
| Kubota L3650 | ~36 hp | 1990 – 1993 |
| Kubota L3300 | 35.1 hp | 1994 – 1999 |
| Kubota L3600 | 38.5 hp | 1994 – 1999 |
| Kubota L4200 | 45.3 hp | 1994 – 1999 |
| Kubota L3710 | ~37 hp | 1998 – 2002 |
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | Diesel |
| Cylinders | 4 |
| Displacement | 1.9 L |
| Gross Engine Power | 38.5 hp (28.7 kW) |
| Net Engine Power | 35.7 hp (26.6 kW) |
The Kubota diesel engine used in the L3600 provides excellent fuel efficiency, strong torque, and long operating life, making it suitable for demanding farm tasks.
Transmission
| Transmission Type | Description |
|---|---|
| 8-speed synchronized shuttle | Smooth gear shifting for field operations |
| 8-speed power shuttle | Easy directional changes during loader work |
These transmission options provide reliable power delivery and improved productivity for agricultural applications.
Power
| Item | Power |
|---|---|
| Engine Gross Power | 38.5 hp |
| Engine Net Power | 35.7 hp |
| PTO Power | 31 hp |
| Plow Capability | 2 × 14-inch plows |
Mechanical Features
| Feature | Details |
|---|---|
| Drive | 2WD or 4WD |
| Steering | Power steering |
| Brakes | Wet disc brakes |
| Safety | Two-post ROPS |
These features ensure stable operation and improved safety during heavy-duty tasks.
Hydraulics
| Specification | Value |
|---|---|
| Hydraulic Type | Open center |
| Hydraulic Capacity | 10.3 gal (39.0 L) |
| Pressure | 2490 psi (171.7 bar) |
| Pump Flow | 7.8 gpm (29.5 L/min) |
The hydraulic system allows efficient operation of loaders, backhoes, and other implements.
Tractor Hitch
| Specification | Value |
|---|---|
| Rear Hitch Type | Category I |
| Hitch Control | Position control |
| Lift Capacity (at ends) | 2,870 lbs (1301 kg) |
| Lift Capacity (24″/610mm) | 2,310 lbs (1047 kg) |
Power Take-Off (PTO)
| Specification | Value |
|---|---|
| Rear PTO | Independent |
| Rear PTO Speed | 540 rpm |
| PTO Shaft Size | 1.375 inch |
| Mid PTO | Independent |
| Mid PTO Speed | 2000 rpm |
Capacity
| Item | Capacity |
|---|---|
| Fuel Tank | 9.2 gal (34.8 L) |
| Hydraulic System | 10.3 gal (39.0 L) |
Dimensions & Tires
| Specification | Value |
|---|---|
| Wheelbase (2WD) | 71.3 inches (181 cm) |
| Wheelbase (4WD) | 71.1 inches (180 cm) |
| Weight | 2,800 – 2,955 lbs |
| Front Tires | 6.00-16 |
| Rear Tires | 13.6-24 (2WD) |
The compact size of the L3600 allows it to work efficiently in orchards, small farms, and tight spaces.
Electrical
| Specification | Value |
|---|---|
| Ground | Negative |
| Battery CCA | 447 |
| Battery Voltage | 12V |
Available Attachments
The Kubota L3600 supports a wide range of implements, making it a versatile work tractor.
| Attachment | Use |
|---|---|
| 72″ mid-mount mower deck | Grass cutting |
| Snowblower | Snow removal |
| Blade | Land leveling |
| Front-end loader | Material handling |
| Backhoe | Excavation |
Photos
Kubota L3600 tractor with loader configuration.
(Insert tractor image here)
Why the Kubota L3600 Remains Popular
The Kubota L3600 continues to be valued by farmers and equipment operators because of:
-
Reliable Kubota diesel engine
-
Strong 38.5 hp performance
-
Durable Grand L Series design
-
Multiple transmission options
-
Compatibility with many attachments
These features make the Kubota L3600 a dependable compact tractor for agriculture, landscaping, and property maintenance around the world.
