Massey Ferguson 3245 – Specifications and Overview
The Massey Ferguson 3245 is a powerful orchard and vineyard tractor designed for specialized agricultural environments such as fruit orchards, vineyards, and narrow-row plantations. Produced between 1999 and 2001, the MF 3245 belongs to the Massey Ferguson 3200 Series, known for strong performance, compact maneuverability, and dependable diesel engines.
Powered by a Perkins 4.0-liter four-cylinder diesel engine, the tractor produces approximately 91 horsepower (67.9 kW). This level of power makes the MF 3245 ideal for demanding orchard work, spraying, mowing, cultivation, and hauling operations.
The tractor features two- or four-wheel drive configurations, electro-hydraulic differential lock, power steering, and hydraulic wet disc brakes. Operators benefit from a folding ROPS safety frame, while an optional air-conditioned cab provides additional comfort for extended working hours.
Because of its strong hydraulic capacity and high lift capability, the Massey Ferguson 3245 can operate a wide range of agricultural implements, making it a versatile tractor for professional farming operations.
Overview
| Item | Specification |
|---|---|
| Model | Massey Ferguson 3245 |
| Series | 3200 Series |
| Production Years | 1999 – 2001 |
| Tractor Type | Orchard / Vineyard Tractor |
| Manufacturer | Massey Ferguson |
| Drive Options | 2WD or 4WD |
| Safety | Folding two-post ROPS |
| Cab | Optional with air-conditioning |
Series Position
| Model | Power |
|---|---|
| 3235 | 59.7 kW |
| 3245 | 67.9 kW |
| 3255 | 70.8 kW |
Previous generation: MF 394S (1994–1999)
Next generation: MF 3350 Series (2001–2003)
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Type | Diesel |
| Cylinders | 4 |
| Displacement | 4.0 L |
| Rated Power | 91 hp (67.9 kW) |
| Fuel Tank Capacity | 11.9 gal (45 L) |
The Perkins diesel engine provides excellent torque, fuel efficiency, and reliability, making it suitable for continuous agricultural operations.
Transmission
| Feature | Specification |
|---|---|
| Standard Transmission | 12-speed partially synchronized |
| Optional Transmission | 24-speed creeper |
| Drive System | Mechanical |
| Differential Lock | Electro-hydraulic rear |
These transmission options allow operators to maintain precise working speeds during orchard operations.
Mechanical Features
| Feature | Specification |
|---|---|
| Steering | Power steering |
| Brakes | Hydraulic wet disc brakes |
| Drive | Two- or four-wheel drive |
| Safety Frame | Folding ROPS |
| Cab Option | Yes (with air conditioning) |
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic System | Open center |
| Pressure | 2465 psi (170 bar) |
| Pump Flow | 14 gpm (53 L/min) |
Tractor Hitch
| Feature | Specification |
|---|---|
| Hitch Category | Category II |
| Control | Position and draft control |
| Rear Lift Capacity | 5732 lbs (2600 kg) |
This lift capacity allows the tractor to handle a wide variety of orchard and vineyard implements.
Power Take-Off (PTO)
| Feature | Specification |
|---|---|
| PTO Type | Independent |
| PTO Speeds | 540 / 1000 rpm |
| Optional | 540 / 540E |
| PTO Clutch | Dry disc |
PTO Engine Speed
| PTO Mode | Engine RPM |
|---|---|
| 540 PTO | 1944 rpm |
| 540E PTO | 1375 rpm |
| 1000 PTO | 1916 rpm |
Dimensions & Tires
| Item | Specification |
|---|---|
| 2WD Wheelbase | 85.6 in (217 cm) |
| 4WD Wheelbase | 84 in (213 cm) |
| Front Tire | 7.50-15 |
| Rear Tire (2WD) | 380/70-28 |
The narrow wheelbase and orchard-specific design make the tractor well suited for tight agricultural spaces and specialty crop farming.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Battery Voltage | 12 V |
| Battery Capacity | 95 AH |
Photos
Currently, no official reference photos of the Massey Ferguson 3245 are available in the standard dataset. However, it shares design characteristics with other Massey Ferguson 3200 Series orchard tractors, including a compact body, narrow chassis, and durable Perkins diesel engine.
