Massey Ferguson 3235 – Specifications and Overview
The Massey Ferguson 3235 is a powerful and compact orchard and vineyard tractor designed for agricultural operations where maneuverability and reliability are essential. Manufactured between 1999 and 2001, the 3235 belongs to the Massey Ferguson 3200 Series, a lineup known for durability and efficient diesel performance.
Equipped with a Perkins 4.2-liter four-cylinder diesel engine, the tractor delivers approximately 80 horsepower (59.7 kW). This engine provides strong torque and fuel efficiency, making the tractor suitable for orchard management, vineyard operations, spraying, mowing, and transport tasks.
The model features two- or four-wheel drive configurations, hydraulic wet disc brakes, and a partially synchronized transmission system. In addition, operators benefit from power steering, a folding ROPS safety structure, and optional cab configurations with air conditioning for increased comfort during long working hours.
Because of its compact design and strong lifting capacity, the MF 3235 is particularly well suited for narrow field conditions and specialized crop production environments.
Overview
| Item | Specification |
|---|---|
| Model | Massey Ferguson 3235 |
| Series | 3200 Series |
| Production Years | 1999 – 2001 |
| Tractor Type | Orchard / Vineyard Tractor |
| Manufacturer | Massey Ferguson |
| Drive Options | 2WD or 4WD |
| ROPS | Folding two-post mid-mount |
| Cab | Optional with air-conditioning |
Series Position
| Previous Series | Model Range | Power |
|---|---|---|
| 384S (1994-1999) | Earlier orchard tractor | |
| 3225 | 50.7 kW | |
| 3235 | 59.7 kW | |
| 3245 | 67.9 kW | |
| Next Series (2001-2003) | 3340 |
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Type | Diesel |
| Cylinders | 4 |
| Displacement | 4.2 L |
| Rated Power | 80 hp (59.7 kW) |
| Fuel Tank (3235S) | 16.6 gal (62.8 L) |
| Fuel Tank (3235GE) | 11.9 gal (45 L) |
The Perkins diesel engine used in the MF 3235 is known for its reliability, strong torque output, and efficient fuel consumption. This makes it suitable for continuous agricultural operations.
Transmission
| Feature | Specification |
|---|---|
| Standard Transmission | 12-speed partially synchronized |
| Optional Transmission | 24-speed creeper |
| Drive System | Mechanical |
| Differential Lock | Electro-hydraulic rear |
The transmission allows operators to select precise working speeds for orchard spraying, cultivation, or transport.
Mechanical Features
| Feature | Specification |
|---|---|
| Steering | Power steering |
| Brakes | Hydraulic wet disc |
| Drive Options | 2WD or 4WD |
| Safety | Folding ROPS |
| Cab Option | Yes (air-conditioning available) |
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic System | Open center |
| Pressure | 2465 psi (170 bar) |
| Pump Flow | 14 gpm (53 L/min) |
Tractor Hitch
| Feature | Specification |
|---|---|
| Hitch Type | Category II |
| Control | Position and draft control |
| Rear Lift Capacity | 5732 lbs (2600 kg) |
The strong rear lift capacity allows the tractor to handle a wide variety of agricultural implements.
Power Take-Off (PTO)
| Feature | Specification |
|---|---|
| PTO Type | Independent |
| PTO Speeds | 540 / 1000 rpm |
| Optional | 540 / 540E |
| PTO Clutch | Dry disc |
| Engine RPM (540 PTO) | 1944 rpm |
| Engine RPM (540E) | 1375 rpm |
| Engine RPM (1000 PTO) | 1916 rpm |
Dimensions & Tires
| Item | Specification |
|---|---|
| 2WD Wheelbase | 80.9 in (205 cm) |
| 4WD Wheelbase | 79.3 in (201 cm) |
| Front Tire | 7.50-16 |
| Rear Tire | 14.9R24 |
The compact wheelbase and narrow profile make the MF 3235 ideal for orchards, vineyards, and plantations.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Battery Voltage | 12 V |
| Battery Capacity | 95 AH |
Photos
Currently, no official photos of the Massey Ferguson 3235 are available in the reference dataset. However, the tractor shares design characteristics with other Massey Ferguson 3200 Series orchard tractors, including a compact body, narrow wheelbase, and strong diesel engine performance.
