Massey Ferguson 3225 Tractor
The Massey Ferguson 3225 is a specialized orchard and vineyard tractor produced from 1999 to 2001 as part of the Massey Ferguson 3200 Series. Designed for narrow working environments such as orchards, vineyards, and specialty crop farms, this tractor offers excellent maneuverability while still delivering strong engine performance.
The tractor is powered by a Perkins 4.0-liter four-cylinder diesel engine, producing approximately 68 horsepower (50.7 kW). This provides enough power for demanding tasks while maintaining efficient fuel consumption.
With its compact design, optional four-wheel drive, and strong hydraulic system, the Massey Ferguson 3225 is well suited for operating vineyard sprayers, mowers, tillers, and other specialized implements.
Overview
| Item | Details |
|---|---|
| Model | Massey Ferguson 3225 |
| Series | 3200 Series |
| Production Years | 1999 – 2001 |
| Manufacturer | Massey Ferguson |
| Tractor Type | Orchard / Vineyard Tractor |
| Engine Power | 68 hp (50.7 kW) |
| Drive Options | 2WD or 4WD |
| ROPS | Two-post mid-mount folding ROPS |
| Cab | Optional cab with air-conditioning |
Series Map
| Model | Power |
|---|---|
| Massey Ferguson 3220 | 64 hp |
| Massey Ferguson 3225 | 68 hp |
| Massey Ferguson 3235 | 80 hp |
| Next Generation | Massey Ferguson 3330 (2001–2003) |
Previous model: Massey Ferguson 374S (1994–1999)
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Type | Diesel |
| Cylinders | 4-cylinder |
| Displacement | 4.0 L |
| Engine Power | 68 hp (50.7 kW) |
Fuel Tank Capacity
| Variant | Capacity |
|---|---|
| 3225S | 16.6 gal (62.8 L) |
| 3225GE | 11.9 gal (45.0 L) |
The Perkins diesel engine is known for reliability and smooth power delivery, making it well suited for long working hours in specialized agricultural environments.
Transmission
| Specification | Details |
|---|---|
| Transmission Type | Partially synchronized |
| Standard Transmission | 12-speed |
| Optional Transmission | 24-speed creeper |
The creeper gear option allows extremely slow speeds for precision tasks such as spraying or planting.
Mechanical Features
| Specification | Details |
|---|---|
| Drive Options | 2WD or 4WD |
| Differential Lock | Electro-hydraulic rear |
| Steering | Power steering |
| Brakes | Hydraulic wet disc |
These features ensure stable handling and safe operation, even in tight orchard rows.
Hydraulics
| Specification | Details |
|---|---|
| Hydraulic Type | Open center |
| Hydraulic Pressure | 2465 psi (170 bar) |
| Pump Flow | 14 gpm (53 L/min) |
The hydraulic system supports a wide range of agricultural implements used in specialty crop farming.
Tractor Hitch
| Specification | Details |
|---|---|
| Hitch Type | Rear Type II |
| Control | Position and draft control |
| Rear Lift Capacity | 5,732 lbs (2,600 kg) |
Power Take-Off (PTO)
| Specification | Details |
|---|---|
| PTO Type | Independent |
| PTO Clutch | Dry disc |
| PTO Speeds | 540 / 1000 rpm |
| Optional PTO | 540 / 540E |
PTO Engine Speeds
| PTO Speed | Engine RPM |
|---|---|
| 540 | 1944 rpm |
| 540E | 1375 rpm |
| 1000 | 1916 rpm |
Dimensions & Tires
| Specification | Details |
|---|---|
| Wheelbase (2WD) | 80.9 in (205 cm) |
| Wheelbase (4WD) | 79.3 in (201 cm) |
| Front Tire | 7.50-16 |
| Rear Tire (3225S 2WD) | 14.9R24 |
The compact dimensions allow the tractor to operate efficiently in narrow vineyard rows.
Electrical
| Specification | Details |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Battery Voltage | 12V |
| Battery Capacity | 95 AH |
Photos
Currently, official photos of the Massey Ferguson 3225 tractor are limited. Owners who have this model are encouraged to share images to help document the tractor for future users.
✔ The Massey Ferguson 3225 is a reliable orchard tractor designed for precision agricultural work.
Its Perkins diesel engine, compact design, and versatile transmission options make it well suited for vineyards, orchards, and specialty farms worldwide.
