Massey Ferguson 3220 Tractor
The Massey Ferguson 3220 is a compact orchard and vineyard tractor produced between 1999 and 2001 as part of the Massey Ferguson 3200 Series. Designed for specialized agricultural applications, this tractor offers excellent maneuverability and efficiency for work in orchards, vineyards, and other narrow-row farming environments.
Powered by a Perkins 2.7-liter three-cylinder diesel engine, the Massey Ferguson 3220 produces 64 horsepower, providing strong performance while maintaining excellent fuel efficiency. The tractor was available with two-wheel drive or four-wheel drive, allowing farmers to select the most suitable configuration for their terrain.
With dependable hydraulics, versatile transmission options, and operator comfort features such as folding ROPS or optional cab with air-conditioning, the Massey Ferguson 3220 remains a reliable choice for specialized farming operations.
Overview
| Item | Details |
|---|---|
| Model | Massey Ferguson 3220 |
| Series | 3200 Series |
| Production Years | 1999 – 2001 |
| Manufacturer | Massey Ferguson |
| Tractor Type | Orchard / Vineyard Tractor |
| Engine Power | 64 hp (47.7 kW) |
| Drive Options | 2WD or 4WD |
| ROPS | Two-post mid-mount folding ROPS |
| Cab | Optional cab with air-conditioning |
Series Map
| Model | Power |
|---|---|
| Massey Ferguson 3210 | 55 hp |
| Massey Ferguson 3220 | 64 hp |
| Massey Ferguson 3225 | 68 hp |
| Next Generation | Massey Ferguson 3325 (2001–2003) |
Previous series model: Massey Ferguson 364S (1994–1999)
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 2.7 L |
| Engine Power | 64 hp (47.7 kW) |
Fuel Tank Capacity
| Variant | Capacity |
|---|---|
| 3220S | 16.6 gal (62.8 L) |
| 3220GE | 11.9 gal (45.0 L) |
The Perkins diesel engine is known for durability, smooth operation, and excellent fuel efficiency in compact agricultural tractors.
Transmission
| Specification | Details |
|---|---|
| Transmission Type | Partially synchronized |
| Standard Gears | 12-speed |
| Optional Transmission | 24-speed creeper |
The creeper transmission option allows very slow operating speeds, which is ideal for specialized orchard and vineyard tasks.
Mechanical Features
| Specification | Details |
|---|---|
| Drive Options | 2WD or 4WD |
| Steering | Power steering |
| Brakes | Hydraulic wet disc |
These features provide stable handling and reliable braking performance in tight working environments.
Hydraulics
| Specification | Details |
|---|---|
| Hydraulic Type | Open center |
The hydraulic system allows the tractor to operate implements commonly used in orchard and vineyard farming.
Tractor Hitch
| Specification | Details |
|---|---|
| Hitch Type | Rear Type II |
| Control | Position and draft control |
| Lift Capacity | 5,732 lbs (2,600 kg) |
Power Take-Off (PTO)
| Specification | Details |
|---|---|
| PTO Type | Independent |
| PTO Clutch | Dry disc |
| PTO Speeds | 540 / 1000 rpm |
| Optional PTO | 540 / 540E |
PTO Engine Speeds
| PTO Speed | Engine RPM |
|---|---|
| 540 | 1944 rpm |
| 540E | 1375 rpm |
| 1000 | 1916 rpm |
Dimensions & Tires
| Specification | Details |
|---|---|
| Front Tire | Varies by configuration |
| Rear Tire | Varies by configuration |
The compact design of the Massey Ferguson 3220 makes it ideal for narrow working environments such as vineyards and orchards.
Electrical
| Specification | Details |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Battery Voltage | 12V |
| Battery Capacity | 95 AH |
Photos
Currently, official catalog photos of the Massey Ferguson 3220 are limited. Owners and collectors who have this tractor are encouraged to share photos to help document this model.
✔ The Massey Ferguson 3220 is a reliable and efficient orchard tractor designed for specialized farming tasks.
With its Perkins diesel engine, compact size, and flexible transmission options, it continues to be valued by farmers working in vineyards and orchards worldwide.
