New Holland TL5060 Tractor
The New Holland TL5060 is a powerful utility tractor produced from 2007 to 2011 as part of the reliable New Holland TL5000 Series. Designed for versatility and durability, the TL5060 is well suited for medium to large agricultural operations including cultivation, hay work, loader operations, and transport tasks.
Powered by a Weifang-Deutz 4.2-liter 4-cylinder diesel engine, the tractor produces approximately 100 horsepower, delivering strong torque and efficient fuel consumption. This level of power allows the TL5060 to operate larger implements and handle demanding field work.
The tractor is available in two-wheel drive (2WD) or mechanical front-wheel drive (MFWD/4WD) configurations, providing flexibility depending on field conditions and farm requirements. A 12-speed mechanical transmission allows operators to select optimal working speeds for various agricultural applications.
Manufactured in Shanghai, China and Tashkent, Uzbekistan, the TL5060 was designed to provide dependable performance while remaining cost-effective for farmers around the world.
EVERY FARM TRACTOR supplies carefully inspected tractors and agricultural machinery to customers in more than 100 countries worldwide, supporting farmers with reliable equipment.
Overview
| Item | Details |
|---|---|
| Model | New Holland TL5060 |
| Production Years | 2007 – 2011 |
| Series | TL5000 Series |
| Type | Utility Tractor |
| Manufacturer | New Holland |
| Production Locations | Shanghai, China / Tashkent, Uzbekistan |
| Drive Options | 2WD or 4WD (MFWD optional) |
| Steering | Hydrostatic Power Steering |
| Brakes | Hydraulic Wet Disc |
| Operator Station | Open platform |
| Optional Equipment | ROPS or cab with heating and air-conditioning |
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Weifang-Deutz |
| Engine Type | Diesel |
| Cylinders | 4 |
| Displacement | 4.2 L (256 cu in) |
| Rated Engine Power | 100 hp (74.6 kW) |
| Fuel Tank Capacity | 33.6 gal (127.2 L) |
The Weifang-Deutz diesel engine provides dependable power and strong torque for heavy-duty agricultural tasks.
Transmission
| Item | Specification |
|---|---|
| Transmission Type | Mechanical |
| Number of Gears | 12-speed |
The 12-speed transmission allows smooth gear selection for both fieldwork and transport operations.
Power
| Item | Output |
|---|---|
| Engine Power | 100 hp (74.6 kW) |
| PTO Power (claimed) | 87.5 hp (65.2 kW) |
The high PTO power allows the tractor to operate demanding equipment such as balers, rotary cutters, and tillage implements.
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic Valves | 1 to 3 |
| Pump Flow | 11.9 gpm (45.0 L/min) |
The hydraulic system provides reliable performance for loader work and rear-mounted implements.
Hitch
| Item | Specification |
|---|---|
| Rear Hitch Category | Category II |
| Lift Capacity (at ends) | 7,368 lbs (3,342 kg) |
| Lift Capacity (24 in / 610 mm behind) | 4,497 lbs (2,039 kg) |
The strong three-point hitch allows the TL5060 to operate a wide variety of farm implements.
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO Type | Rear PTO |
| PTO Speed | 540 RPM |
| PTO Engagement RPM | 540 @ 2199 engine RPM |
The PTO system supports equipment such as mowers, sprayers, and balers.
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase (2WD) | 96 inches (243 cm) |
| Wheelbase (4WD) | 94.9 inches (241 cm) |
| Operating Weight | 7,022 – 8,488 lbs (3,185 – 3,851 kg) |
| Front Tires | 7.50-16 |
| Rear Tires | 16.9-34 (2WD) |
The stable wheelbase and heavy chassis provide excellent traction and balance during field operations.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery Voltage | 12 V |
| Battery Capacity | 120 Ah |
Photos
Typical features of the New Holland TL5060 tractor include:
-
Classic New Holland blue utility tractor design
-
Large rear agricultural tires for traction
-
Open operator platform or enclosed cab configuration
-
Durable chassis suitable for loader and heavy field work
