Massey Ferguson 2775 Overview
The Massey Ferguson 2775 is a powerful row-crop tractor produced between 1978 and 1983 as part of the renowned Massey Ferguson 2000 Series. Built for heavy-duty agricultural operations, this tractor became popular among large-scale farms due to its strong engine performance, durable construction, and advanced transmission options.
Powered by a Perkins 10.5-liter V8 diesel engine, the MF 2775 delivers approximately 160 horsepower at the PTO, making it well suited for demanding tasks such as deep tillage, large plows, cultivators, and heavy transport operations.
Farmers could choose between a 24-speed power shift transmission or a robust 8-speed mechanical shuttle transmission, providing flexibility depending on working conditions and operator preferences.
The tractor features hydrostatic power steering, hydraulic wet disc brakes, and a strong hydraulic system, ensuring reliable control when operating large implements. A comfortable enclosed cab with air-conditioning was standard, while an open platform with four-post ROPS was also available.
Even decades after its production ended, the Massey Ferguson 2775 remains respected as a durable high-horsepower tractor from one of Massey Ferguson’s most successful tractor generations.
EVERY FARM TRACTOR exports high-quality Japanese used tractors and agricultural equipment to customers in more than 100 countries worldwide, helping farmers access reliable machinery for modern agriculture.
Massey Ferguson 2775 Specifications
Overview
| Item | Details |
|---|---|
| Model | Massey Ferguson 2775 |
| Series | 2000 Series |
| Production Years | 1978 – 1983 |
| Tractor Type | Row-Crop Tractor |
| Manufacturer | Massey Ferguson |
| Original Price | $51,500 (1983) |
Series Map
| Model | Estimated Engine Power |
|---|---|
| MF 2745 | ~155.6 hp |
| MF 2775 | ~177.8 hp |
| MF 2805 | ~211.1 hp |
| MF 2770 | Previous model (1976–1977) |
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Type | Diesel |
| Cylinders | 8-cylinder |
| Displacement | 10.5 L |
| Fuel Tank Capacity | 87 gal (329.3 L) |
Power Output
| Type | Output |
|---|---|
| PTO Power (claimed) | 160 hp (119.3 kW) |
| Drawbar Power (tested) | 139.30 hp (103.9 kW) |
| PTO Power (tested) | 165.95 hp (123.7 kW) |
The Perkins V8 diesel engine provides high torque and excellent pulling capability for large agricultural implements.
Transmission
| Transmission Type | Description |
|---|---|
| 24-speed 3-speed Power Shift | Multi-range power shift transmission |
| 8-speed Mechanical Shuttle | Simple and durable gear transmission |
These transmission options allow efficient operation across various field conditions.
Mechanical Features
| Feature | Specification |
|---|---|
| Drive Type | Two-wheel drive |
| Final Drives | Planetary |
| Steering | Hydrostatic power steering |
| Brakes | Hydraulic wet disc brakes |
| Cab | Standard with air-conditioning |
| Platform Option | Four-post ROPS open station |
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic Type | Open center |
| Valves | 2 or 3 |
| Pump Flow (High pressure) | 17.1 gpm (64.7 L/min) |
| Pump Flow (Low pressure) | 6.6 gpm (25.0 L/min) |
| Auxiliary High Pressure | 17.1 gpm (64.7 L/min) |
| Steering Flow | 5.7 gpm (21.6 L/min) |
This hydraulic system provides sufficient capacity for large implements and loader equipment.
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category III / II |
| Hitch Control | Position control and lower-link draft sensing |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO Type | Independent |
| PTO Clutch | Hydraulic |
| PTO Speed | 1000 RPM |
| PTO Shaft | 1.375 in |
| Engine RPM | 1000 PTO @ 2090 RPM |
Dimensions and Tires
| Item | Specification |
|---|---|
| Wheelbase | 110 in (279 cm) |
| Weight | 13,300 – 16,230 lbs |
| Front Tire | 11.00-16 |
| Rear Tire | 20.8-38 |
The large wheelbase and tire configuration provide excellent traction and stability in heavy field operations.
Attachments
| Attachment | Description |
|---|---|
| Front-End Loader | Heavy-duty loader for material handling |
Serial Numbers
| Year | Serial Number |
|---|---|
| 1978 | 9R000733 |
| 1979 | 9R003482 |
| 1980 | 9R007282 |
| 1981 | 9R010307 |
| 1982 | 9R013230 |
| 1983 | 9R013525 |
Location: Serial number plate located on the left side of the instrument panel.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 58 amps |
| Batteries | 2 |
| Battery Voltage | 12 V |
