Massey Ferguson 2604H Tractor – Detailed Specifications
The Massey Ferguson 2604H is a durable and economical utility tractor introduced in 2016 as part of the Massey Ferguson 2600H Series. Designed for reliability and simple maintenance, this tractor is widely used for small to medium farms, livestock operations, landscaping, and general agricultural work.
Powered by a Simpson 2.6-liter 3-cylinder diesel engine, the MF 2604H produces 45 horsepower and offers excellent torque and fuel efficiency. With two-wheel drive (2WD) or four-wheel drive (4WD) options, a dependable 8-speed gear transmission, and strong hydraulic performance, this model is well suited for loader work, field operations, and everyday farm tasks.
The Massey Ferguson 2604H combines mechanical simplicity with modern usability, making it a popular choice for farmers seeking a dependable and cost-effective tractor.
Overview
| Item | Details |
|---|---|
| Model | Massey Ferguson 2604H |
| Series | 2600H Series |
| Production | 2016 – Present |
| Manufacturer | Massey Ferguson |
| Tractor Type | Utility Tractor |
| Original Price (2017) | $18,535 |
| Drive Options | 2WD or 4WD |
| Engine Power | 45 hp (33.6 kW) |
Series Lineup
| Model | Engine Power |
|---|---|
| MF 2604H | 45 hp |
| MF 2605H | 55 hp |
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | Simpson |
| Engine Type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 2.6 L |
| Gross Engine Power | 45 hp (33.6 kW) |
| Fuel Tank Capacity | 14.5 gal (54.9 L) |
| Cooling System | Liquid-cooled |
The Simpson diesel engine used in the MF 2604H is known for its simple design, durability, and fuel efficiency, making it ideal for long working hours in agricultural environments.
Transmission
| Specification | Details |
|---|---|
| Transmission Type | Gear drive |
| Number of Speeds | 8 forward / 2 reverse |
The 8-speed manual gearbox offers straightforward operation and reliability, especially suited for farmers who prefer mechanical simplicity and easy maintenance.
Power & Performance
| Specification | Details |
|---|---|
| Engine Power | 45 hp (33.6 kW) |
| PTO Power | 38 hp (28.3 kW) |
| PTO Type | Live |
| PTO Speed | 540 rpm |
The live PTO system allows operators to power implements such as mowers, tillers, and balers without stopping the tractor.
Mechanical Features
| Feature | Details |
|---|---|
| Drive System | 2WD or 4WD |
| Differential Lock | Mechanical rear |
| Steering | Power steering |
| Brakes | Drum brakes |
| Safety | Two-post folding ROPS |
These features provide stable handling, improved traction, and operator safety in demanding farming environments.
Hydraulics
| Specification | Details |
|---|---|
| Hydraulic Type | Open center |
| Control Valves | 1 |
| Pump Flow | 10.6 gpm (40.1 L/min) |
| Total Flow | 15.7 gpm (59.4 L/min) |
The hydraulic system supports various implements and attachments used in agricultural and property maintenance work.
Three-Point Hitch
| Specification | Details |
|---|---|
| Hitch Category | Category I / II |
| Rear Lift Capacity (24 in / 610 mm) | 2,204 lbs (999 kg) |
The three-point hitch allows the tractor to operate a wide range of implements such as plows, rotary tillers, and seeders.
Dimensions & Tires
| Specification | Details |
|---|---|
| Wheelbase (2WD) | 80.7 in (204 cm) |
| Wheelbase (4WD) | 81.5 in (207 cm) |
| Weight | 4,597 – 4,927 lbs (2,085 – 2,235 kg) |
| Front Tires | 6×16 |
| Rear Tires | 12.4×28 |
The balanced size and weight of the MF 2604H provide good stability and traction for field operations and loader work.
Attachments
The Massey Ferguson 2604H is commonly equipped with various implements.
| Attachment | Description |
|---|---|
| Front-End Loader | For lifting, loading, and material handling |
These attachments make the tractor highly versatile for daily farm operations.
Electrical System
| Specification | Details |
|---|---|
| Ground | Negative |
| Battery Voltage | 12V |
Photos
Currently, official photos of the Massey Ferguson 2604H are limited in public databases. Owners who have photographs of this model may submit them to tractor reference websites or manufacturer communities.
