🚜 Kubota KT235 – Compact Utility Tractor (KT Kingeye Series)
EVERY FARM TRACTOR has been exporting high-quality Japanese used tractors and agricultural machinery to over 100 countries since 2006.
The Kubota KT235 is a mid-range model in the updated KT Kingeye Series (2009–2011), offering improved engine refinement, strong PTO output, and excellent maneuverability.
Overview
| Item | Specification |
|---|---|
| Manufacturer | Kubota |
| Model | KT235 |
| Series | KT Kingeye Series |
| Production Years | 2009 – 2011 |
| Type | Compact Utility Tractor |
| Drive System | 4WD |
| Steering | Power Steering |
| Brakes | Wet Disc |
| Safety | Two-post Folding ROPS |
| Optional | Cabin with Air Conditioning |
🔎 Series Position
| Model | Power (kW) | Approx. HP | Production |
|---|---|---|---|
| KT230 | 16.9 kW | 22.7 hp | 2005–2008 |
| KT235 | 16.9 kW | 22.7 hp | 2009–2011 |
| KT255 | 18.4 kW | 24.7 hp | 2009–2011 |
| FT23 | ↑ Successor model | — | 2012–2015 |
The KT235 replaced the KT230 and introduced refined engine tuning and updated styling while maintaining the same power class.
Engine
The Kubota KT235 is powered by a durable Kubota 3-cylinder diesel engine designed for smooth and efficient operation.
| Item | Specification |
|---|---|
| Engine Type | Kubota 3-cylinder Diesel |
| Displacement | 1.5 L (approx. 1,498 cc class) |
| Gross Engine Power | 22.7 hp (16.9 kW) |
| Rated RPM | 2500 rpm |
| Fuel Tank Capacity | 28.0 L (7.4 gal) |
| Cooling | Liquid-cooled |
The engine provides stable torque delivery suitable for rotary tilling and general agricultural tasks.
Transmission
Kubota provided flexible transmission options to meet various farming requirements.
| Transmission Type | Description |
|---|---|
| 12-speed Manual | Standard gear transmission |
| 48-speed Power Shift | Advanced multi-range power shift |
The 48-speed option allows precise speed adjustment for field and orchard operations.
Power & PTO
| Item | Specification |
|---|---|
| Engine Power | 22.7 hp |
| Drive Type | 4WD |
| Rear PTO | 540 rpm (1.375 inch shaft) |
| PTO Engine RPM | 505 / 731 / 1136 rpm @ 2500 rpm |
Compatible implements:
-
Rotary tillers
-
Rear mowers
-
Sprayers
-
Post hole diggers
-
Small trailers
Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 150 cm (59.1 inches) |
| Weight | 930 – 1,060 kg (2,050 – 2,337 lbs) |
| Front Tire | 6-14 |
| Rear Tire | 9.5-22 |
The KT235 maintains compact dimensions while offering improved traction and stability.
Mechanical Features
| Feature | Description |
|---|---|
| Drive | Four-Wheel Drive |
| Steering | Power Steering |
| Brakes | Wet Disc Brakes |
| Safety | Folding ROPS |
| Optional | Cabin with Air Conditioning |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery | 12V |
Why Choose the Kubota KT235?
✅ Balanced 22.7HP performance
✅ Efficient 1.5L Kubota diesel engine
✅ 4WD traction for uneven terrain
✅ Compact yet powerful for mixed operations
✅ Ideal for orchards and small-to-medium farms
The KT235 is widely exported to Africa, Southeast Asia, the Caribbean, and Pacific regions where durability and efficiency are essential.
Photos
Currently, no official catalog photos are available for the Kubota KT235.
Please contact EVERY FARM TRACTOR for actual stock photos and availability.
🌍 Worldwide Export Support by EVERY FARM TRACTOR
We provide:
-
Pre-export inspection
-
Container & RoRo shipping
-
Fast documentation processing
-
Spare parts supply
If you are looking for a reliable 22HP class compact 4WD tractor, the Kubota KT235 is a dependable and practical solution.
