🚜 Kubota KT230 – Compact Utility Tractor (KT Kingeye Series)
EVERY FARM TRACTOR has exported high-quality Japanese used tractors and agricultural machinery to over 100 countries since 2006.
The Kubota KT230 is a mid-range model in the 2005–2008 KT Kingeye Series, offering increased horsepower and excellent balance between power and compact size.
Overview
| Item | Specification |
|---|---|
| Manufacturer | Kubota |
| Model | KT230 |
| Series | KT Kingeye Series |
| Production Years | 2005 – 2008 |
| Type | Compact Utility Tractor |
| Drive System | 4WD |
| Steering | Power Steering |
| Brakes | Wet Disc |
| Safety | Two-post Folding ROPS |
| Optional | Cabin with Air Conditioning |
🔎 Series Position
| Model | Power (kW) | Approx. HP | Production |
|---|---|---|---|
| KT210 | 15.4 kW | 20.7 hp | 2005–2008 |
| KT230 | 16.9 kW | 22.7 hp | 2005–2008 |
| KT250 | 18.4 kW | 24.7 hp | 2005–2008 |
| KT235 | ↑ Updated model | — | 2009–2011 |
| KT22 | ↓ Previous model | 16.2 kW | 2000–2004 |
The KT230 replaced the earlier KT22 and offered improved styling and refined engine performance.
Engine
The Kubota KT230 is powered by a reliable Kubota 3-cylinder diesel engine designed for smooth operation and fuel efficiency.
| Item | Specification |
|---|---|
| Engine Type | Kubota 3-cylinder Diesel |
| Displacement | 1.5 L (approx. 1,498 cc class) |
| Gross Engine Power | 22.7 hp (16.9 kW) |
| Rated RPM | 2500 rpm |
| Fuel Tank Capacity | 28.0 L (7.4 gal) |
| Cooling | Liquid-cooled |
The engine delivers strong low-end torque, making it suitable for rotary tilling and general farm operations.
Transmission
Kubota offered versatile transmission options for different agricultural applications.
| Transmission Type | Description |
|---|---|
| 12-speed Manual | Standard mechanical transmission |
| 48-speed Power Shift | Multi-range power shift for precision control |
The 48-speed configuration allows accurate speed adjustment for field and transport work.
Power & PTO
| Item | Specification |
|---|---|
| Engine Power | 22.7 hp |
| Drive Type | 4WD |
| Rear PTO | 540 rpm (1.375 inch shaft) |
| PTO Engine RPM | 505 / 731 / 1136 rpm @ 2500 rpm |
Compatible implements include:
-
Rotary tillers
-
Rear mowers
-
Sprayers
-
Post hole diggers
-
Small loaders
Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 150 cm (59.1 inches) |
| Weight | 930 – 1,060 kg (2,050 – 2,337 lbs) |
| Front Tire | 6-14 |
| Rear Tire | 9.5-22 |
The KT230 provides improved rear traction compared to the smaller KT210 due to its larger rear tire size.
Mechanical Features
| Feature | Description |
|---|---|
| Drive | Four-Wheel Drive |
| Steering | Power Steering |
| Brakes | Wet Disc Brakes |
| Safety | Folding ROPS |
| Optional | Cabin with Air Conditioning |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery | 12V |
Why Choose the Kubota KT230?
✅ Balanced 22.7HP performance
✅ Durable 1.5L Kubota diesel engine
✅ 4WD traction for uneven terrain
✅ Compact size with strong PTO output
✅ Ideal for small to medium farming operations
The KT230 is popular in export markets across Africa, Southeast Asia, the Caribbean, and Pacific regions where compact tractors are essential for mixed agricultural work.
Photos
Currently, no official catalog photos are available for the Kubota KT230.
Please contact EVERY FARM TRACTOR for current stock availability and actual unit photos.
🌍 Worldwide Export Support by EVERY FARM TRACTOR
We provide:
-
Pre-export inspection
-
Container & RoRo shipping
-
Fast documentation support
-
Spare parts supply
If you are looking for a reliable 22HP class 4WD compact tractor, the Kubota KT230 is a practical and dependable solution.
