New Holland T7060
210HP Heavy-Duty Row-Crop Tractor – T7000 Series
Overview
The New Holland T7060 is a high-performance row-crop tractor from the T7000 Series, produced between 2007 and 2011.
Manufactured in Basildon, England, this model was designed for large-scale and demanding agricultural operations requiring strong drawbar power, high PTO performance, and advanced hydraulic capability.
Positioned between the T7050 and T7070, the T7060 offers a balance of power, control, and operator comfort suitable for heavy tillage, transport, and intensive PTO applications.
Series lineup:
-
T7050 – 195 HP
-
T7060 – 210 HP
-
T7070 – 225 HP
(Successor: T7.260, 2011–2013)
Engine
| Item | Specification |
|---|---|
| Engine manufacturer | FPT (Fiat Powertrain Technologies) |
| Engine type | Diesel |
| Cylinders | 6-cylinder |
| Displacement | 6.7 L |
| Aspiration | Turbocharged |
| Cooling | Liquid-cooled |
The proven FPT 6.7L engine delivers strong torque and reliability under continuous heavy-duty operation.
Power Output
| Measurement | Output |
|---|---|
| Engine power | 210 HP / 156.6 kW |
| PTO power (claimed) | 180 HP / 134.2 kW |
| Drawbar power (tested) | 155.8 HP / 116.2 kW |
| PTO power (tested) | 203.0 HP / 151.4 kW |
Transmission
| Option | Details |
|---|---|
| 18-speed | Full power shift |
| 19-speed | Full power shift |
| CVT | Continuously Variable Transmission |
| 28-speed | Advanced configuration |
Multiple transmission options allow operators to tailor performance for fieldwork, transport, and PTO-driven tasks.
Axle & Steering Options
| Feature | Description |
|---|---|
| TerraGlide front axle | 4.13 in (105 mm) suspension travel for improved ride and traction |
| SuperSteer front axle | 19° axle pivot + 46° wheel pivot for tight turning radius |
| Steering | Hydrostatic power steering |
Hydraulics
| Item | Specification |
|---|---|
| System type | Closed Center Load Sensing (CCLS) |
| Hydraulic capacity | 26.5 gal / 100.3 L |
| Rear remote valves | 3 to 5 |
| Pump flow | 32.0 gpm / 121.1 lpm |
| Optional MegaFlow | 39.6 gpm / 149.9 lpm |
| Total flow | 49.0 gpm / 185.5 lpm |
| Total flow (optional) | 56.6 gpm / 214.2 lpm |
| Steering flow | 17.6 gpm / 66.6 lpm |
Hitch & Lift Capacity
Rear Hitch
| Item | Specification |
|---|---|
| Hitch type | Category 3 / 2 |
| Control | Electronic lower-link draft control |
| Lift at hitch ends | 19,060 lbs / 8,645 kg |
| Lift at 24 in (610 mm) | 15,873 lbs / 7,199 kg |
Front Hitch
| Item | Specification |
|---|---|
| Front lift capacity | 7,981 lbs / 3,620 kg |
| With SuperSteer axle | 6,019 lbs / 2,730 kg |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO type | Independent |
| PTO clutch | Electro-hydraulic wet disc |
| PTO speeds | 540 / 1000 rpm |
| Optional PTO | 540E / 1000, 1000 (1.75 in) |
Capacities
| Item | Capacity |
|---|---|
| Fuel tank (early) | 116.2 gal / 439.8 L |
| Fuel tank (late) | 107.0 gal / 405.0 L |
| Hydraulic system | 26.5 gal / 100.3 L |
Dimensions & Weight
| Item | Specification |
|---|---|
| Wheelbase (standard) | 113.5 in / 288 cm |
| Wheelbase (SuperSteer) | 117.2 in / 297 cm |
| Operating weight | 15,708 – 17,915 lbs |
| Front tire | 600/65R28 |
| Rear tire | 710/70R38 |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging system | Alternator |
| Output | 150 amps |
| Optional output | 200 amps |
| Battery capacity | 1300 CCA |
| Voltage | 12 V |
Operator Environment & Features
-
Horizon Cab with heating and air-conditioning
-
Optional deluxe cab with air-ride heated seat
-
Automatic temperature control
-
Heated mirrors
-
Electro-hydraulic rear differential lock
-
Hydraulic wet disc brakes
-
Optional hydraulic trailer brakes
Attachments
| Attachment | Availability |
|---|---|
| Front-end loader | Supported |
