New Holland T7040
180HP High-Performance Row-Crop Tractor – T7000 Series
Overview
The New Holland T7040 is a high-output row-crop tractor from the T7000 Series, produced between 2007 and 2011.
Built in Basildon, England, this model was designed for large-scale farming operations that require strong engine performance, advanced transmission flexibility, and powerful hydraulic capacity.
Positioned between the T7030 and T7050, the T7040 delivers a balanced combination of power and control, making it suitable for heavy tillage, large implements, and intensive PTO applications.
Series lineup:
-
T7030 – 156 HP
-
T7040 – 180 HP
-
T7050 – 195 HP
(Successor: T7.235, 2011–2013)
Engine
| Item | Specification |
|---|---|
| Engine manufacturer | FPT (Fiat Powertrain Technologies) |
| Engine type | Diesel |
| Cylinders | 6-cylinder |
| Displacement | 6.7 L |
| Aspiration | Turbocharged |
| Cooling | Liquid-cooled |
The FPT 6.7L engine provides strong torque delivery and proven durability for demanding field and transport operations.
Power Output
| Measurement | Output |
|---|---|
| Engine power | 180 HP / 134.2 kW |
| PTO power (claimed) | 150 HP / 111.9 kW |
| Drawbar power (tested) | 132.7 HP / 99.0 kW |
| PTO power (tested) | 179.8 HP / 134.1 kW |
Transmission
| Option | Details |
|---|---|
| 18-speed | Full power shift |
| 19-speed | Full power shift |
| CVT | Continuously Variable Transmission |
| 28-speed | Advanced configuration |
These transmission options allow operators to match performance precisely to fieldwork, transport, and PTO tasks.
Axle & Steering Options
| Feature | Description |
|---|---|
| TerraGlide front axle | 4.13 in (105 mm) suspension travel for improved traction and ride comfort |
| SuperSteer front axle | 19° axle pivot + 46° wheel pivot for tighter turning radius |
| Steering | Hydrostatic power steering |
Hydraulics
| Item | Specification |
|---|---|
| System type | Closed Center Load Sensing (CCLS) |
| Hydraulic capacity | 26.5 gal / 100.3 L |
| Rear remote valves | 3 to 5 |
| Pump flow | 32.0 gpm / 121.1 lpm |
| Optional MegaFlow | 39.6 gpm / 149.9 lpm |
| Total flow | 49.0 gpm / 185.5 lpm |
| Total flow (optional) | 56.6 gpm / 214.2 lpm |
| Steering flow | 17.6 gpm / 66.6 lpm |
Hitch & Lift Capacity
Rear Hitch
| Item | Specification |
|---|---|
| Hitch type | Category 3 / 2 |
| Control | Electronic lower-link draft control |
| Lift at hitch ends | 19,060 lbs / 8,645 kg |
| Lift at 24 in (610 mm) | 12,787 lbs / 5,800 kg |
Front Hitch
| Item | Specification |
|---|---|
| Front lift capacity | 7,981 lbs / 3,620 kg |
| With SuperSteer axle | 6,019 lbs / 2,730 kg |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO type | Independent |
| PTO clutch | Electro-hydraulic wet disc |
| PTO speeds | 540 / 1000 rpm |
| Optional PTO | 540E / 1000, 1000 (1.75 in) |
Capacities
| Item | Capacity |
|---|---|
| Fuel tank (early) | 116.2 gal / 439.8 L |
| Fuel tank (late) | 107.0 gal / 405.0 L |
| Hydraulic system | 26.5 gal / 100.3 L |
Dimensions & Weight
| Item | Specification |
|---|---|
| Wheelbase (standard) | 113.5 in / 288 cm |
| Wheelbase (SuperSteer) | 117.2 in / 297 cm |
| Operating weight | 15,708 – 17,595 lbs |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging system | Alternator |
| Output | 150 amps |
| Optional output | 200 amps |
| Battery capacity | 1300 CCA |
| Voltage | 12 V |
Operator Environment & Features
-
Cab with air-conditioning
-
Hydrostatic power steering
-
Electro-hydraulic rear differential lock
-
Hydraulic wet disc brakes
-
Optional hydraulic trailer brakes
Attachments
| Attachment | Availability |
|---|---|
| Front-end loader | Supported |
