New Holland T7030
156HP High-Performance Row-Crop Tractor – T7000 Series
Overview
The New Holland T7030 is a powerful row-crop tractor from the T7000 Series, produced between 2007 and 2011.
Manufactured in Basildon, England, this model was developed for professional farming operations requiring high horsepower, advanced transmission options, and excellent hydraulic performance.
The T7030 sits between the T7040 and later T7-series models, offering a strong balance of power, versatility, and operator comfort.
Series lineup:
-
T7030 – 156 HP
-
T7040 – 180 HP
-
(Successor models: T7.220, 2011–2013)
Engine
| Item | Specification |
|---|---|
| Engine manufacturer | FPT (Fiat Powertrain Technologies) |
| Engine type | Diesel |
| Cylinders | 6-cylinder |
| Displacement | 6.7 L |
| Aspiration | Turbocharged |
| Cooling | Liquid-cooled |
The 6.7L FPT engine delivers strong torque characteristics and proven reliability, suitable for heavy tillage and PTO-intensive work.
Power Output
| Measurement | Output |
|---|---|
| Engine power | 156 HP / 116.3 kW |
| PTO power (claimed) | 135 HP / 100.7 kW |
| Drawbar power (tested) | 107.0 HP / 79.8 kW |
| PTO power (tested) | 163.2 HP / 121.7 kW |
Transmission
| Option | Details |
|---|---|
| 18-speed | Full power shift |
| 19-speed | Full power shift |
| CVT | Continuously Variable Transmission |
| 28-speed | Advanced configuration |
These transmission options allow operators to tailor the tractor for fieldwork, transport, or precision PTO applications.
Axle & Steering Options
| Feature | Description |
|---|---|
| TerraGlide front axle | 4.13 in (105 mm) suspension travel for improved ride and traction |
| SuperSteer front axle | 19° axle pivot + 46° wheel pivot for tight turning radius |
| Steering | Hydrostatic power steering |
Hydraulics
| Item | Specification |
|---|---|
| System type | Closed Center Load Sensing (CCLS) |
| Hydraulic capacity | 26.5 gal / 100.3 L |
| Rear remote valves | 3 to 5 |
| Pump flow | 32.0 gpm / 121.1 lpm |
| Optional MegaFlow | 39.6 gpm / 149.9 lpm |
| Total flow | 49.0 gpm / 185.5 lpm |
| Total flow (optional) | 56.6 gpm / 214.2 lpm |
| Steering flow | 17.6 gpm / 66.6 lpm |
Hitch & Lift Capacity
Rear Hitch
| Item | Specification |
|---|---|
| Hitch type | Category 3 / 2 |
| Control | Electronic lower-link draft control |
| Lift at hitch ends | 19,060 lbs / 8,645 kg |
| Lift at 24 in (610 mm) | 12,787 lbs / 5,800 kg |
Front Hitch
| Item | Specification |
|---|---|
| Front lift capacity | 7,981 lbs / 3,620 kg |
| With SuperSteer axle | 6,019 lbs / 2,730 kg |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO type | Independent |
| PTO clutch | Electro-hydraulic wet disc |
| PTO speeds | 540 / 1000 rpm |
| Optional PTO | 540E / 1000, 1000 (1.75 in) |
Capacities
| Item | Capacity |
|---|---|
| Fuel tank (early) | 116.2 gal / 439.8 L |
| Fuel tank (late) | 107.0 gal / 405.0 L |
| Hydraulic system | 26.5 gal / 100.3 L |
Dimensions & Weight
| Item | Specification |
|---|---|
| Wheelbase (standard) | 113.5 in / 288 cm |
| Wheelbase (SuperSteer) | 117.2 in / 297 cm |
| Operating weight | 15,708 – 17,725 lbs |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging system | Alternator |
| Output | 150 amps |
| Optional output | 200 amps |
| Battery capacity | 1300 CCA |
| Voltage | 12 V |
Operator Environment & Features
-
Horizon Cab (standard) with heating and air-conditioning
-
Optional deluxe cab with air-ride heated seat
-
Automatic temperature control
-
Heated mirrors
-
Electro-hydraulic rear differential lock
-
Hydraulic wet disc brakes
-
Optional hydraulic trailer brakes
Attachments
| Attachment | Availability |
|---|---|
| Front-end loader | Supported |
