Kubota KL360 Compact Utility Tractor
Overview
The Kubota KL360 is a high-performance compact utility tractor from Kubota’s KL Series, produced between 2006 and 2007.
Positioned above the KL330 and below the KL430, the KL360 delivers significantly higher engine output while maintaining the compact utility design that the KL Series is known for.
With a powerful Kubota diesel engine, robust drivetrain, and strong PTO capability, the KL360 is ideal for demanding agricultural operations, heavy implement use, and utility applications requiring higher horsepower.
Key Specifications Overview
| Item | Specification |
|---|---|
| Model | Kubota KL360 |
| Series | KL Series |
| Production Years | 2006 – 2007 |
| Tractor Type | Compact Utility Tractor |
| Drive System | 4WD |
| Steering | Power Steering |
| Brakes | Mechanical wet disc |
| ROPS | Two-post ROPS (Cab optional) |
Engine
The Kubota KL360 is powered by a durable Kubota diesel engine, engineered for consistent output and long working hours.
| Item | Specification |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | Diesel |
| Cylinders | 3 |
| Displacement | 1.5 L |
| Rated Engine Power | 35.5 hp (26.5 kW) |
| Fuel Tank Capacity | 10.6 gal (40.1 L) |
| Electrical System | 12V, Negative Ground |
This engine provides strong torque and stable performance, suitable for heavy-duty PTO-driven implements.
Transmission
The KL360 offers versatile transmission options to suit both field work and transport needs.
| Transmission Type | Details |
|---|---|
| Mechanical | Yes |
| Available Gears | 16-speed / 24-speed |
| Drive | Four-wheel drive |
The wide gear range allows precise speed control for various farming and utility tasks.
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| Rear PTO Type | 540 rpm (1.375 in) |
| PTO Speeds @ 2700 rpm | 533 / 752 / 931 / 1241 |
| Reverse PTO | -931 @ 2700 rpm |
The PTO system supports a wide variety of implements such as rotary tillers, mowers, balers, and spreaders.
Hitch System
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
Compatible with standard Category I implements commonly used in compact and utility farming.
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 75.2 in (191 cm) |
| Operating Weight | 3,285 – 3,682 lb |
| Front Tire Size | 8-18 |
| Rear Tire Size | 12.4-28 |
The longer wheelbase and larger tires provide enhanced stability and traction during high-load operations.
Braking & Chassis
| Item | Specification |
|---|---|
| Braking System | Mechanical wet disc brakes |
| Frame Type | Compact utility tractor frame |
Wet disc brakes ensure reliable stopping power under demanding working conditions.
KL Series Position
| Model | Production Years | Power Output |
|---|---|---|
| KL330 | 2006 – 2007 | 24.3 kW |
| KL360 | 2006 – 2007 | 26.5 kW |
| KL430 | 2006 – 2007 | 31.6 kW |
| KL385 | 2008 – 2009 | Successor |
| KL36 | 1999 – 2005 | Previous generation |
Photos
Currently, no official photos of the Kubota KL360 are available.
Submitted images may be used only with permission from the original photographer.
Why Choose the Kubota KL360?
-
35.5 hp engine for demanding agricultural work
-
Strong PTO output for heavy implements
-
Stable chassis with longer wheelbase
-
Reliable 4WD performance in tough conditions
