Kubota KL285 Compact Utility Tractor
Overview
The Kubota KL285 is a compact utility tractor from Kubota’s KL Series, produced between 2008 and 2009.
Positioned as the successor to the KL270, the KL285 offers improved refinement while maintaining the same proven power output, making it a reliable choice for farming, land maintenance, and light transport tasks.
Available in both standard and high-speed (KL285H) variants, this model delivers excellent versatility, durability, and operator comfort.
Key Specifications Overview
| Item | Specification |
|---|---|
| Model | Kubota KL285 |
| Series | KL Series |
| Production Years | 2008 – 2009 |
| Tractor Type | Compact Utility Tractor |
| Variants | KL285 (Standard), KL285H (High-Speed) |
| Drive System | 4WD |
| Steering | Power Steering |
| Brakes | Mechanical wet disc |
| ROPS | Two-post ROPS (Cab optional) |
Engine
The Kubota KL285 is powered by a dependable Kubota diesel engine designed for long operating hours and low fuel consumption.
| Item | Specification |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | Diesel |
| Cylinders | 3 |
| Displacement | 1.6 L |
| Rated Engine Power | 27.6 hp (20.6 kW) |
| Fuel Tank Capacity | 9.5 gal (36.0 L) |
| Electrical System | 12V, Negative Ground |
This engine provides smooth torque delivery, ideal for PTO-driven implements and daily agricultural use.
Transmission
Multiple transmission options allow operators to select the best configuration for their working environment.
| Transmission Type | Details |
|---|---|
| Mechanical | Yes |
| Available Gears | 16-speed / 24-speed |
| High-Speed Variant | KL285H available |
| Drive | Four-wheel drive |
The wide gear range supports precision control during field work and efficient transport operations.
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| Rear PTO Type | 540 rpm (1.375 in) |
| PTO Speeds @ 2700 rpm | 561 / 791 / 980 / 1307 |
| Reverse PTO | -980 @ 2700 rpm |
The PTO system supports a wide range of implements such as rotary tillers, mowers, and spreaders.
Hitch System
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
Compatible with standard Category I implements for small to medium-scale farm operations.
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 67.7 in (171 cm) |
| Operating Weight | 2,833 – 3,285 lb |
| Front Tire Size | 7-16 |
| Rear Tire Size | 12.4-24 |
The balanced chassis ensures stability while maintaining compact dimensions for easy maneuverability.
Braking & Chassis
| Item | Specification |
|---|---|
| Braking System | Mechanical wet disc brakes |
| Frame Type | Compact utility tractor frame |
Wet disc brakes provide consistent stopping power even under heavy load conditions.
KL Series Position
| Model | Production Years | Power Output |
|---|---|---|
| KL265 | 2008 – 2009 | 19.1 kW |
| KL285 | 2008 – 2009 | 20.6 kW |
| KL315 | 2008 – 2009 | 22.8 kW |
| KL270 | 2006 – 2007 | Previous generation |
Photos
Currently, no official photos of the Kubota KL285 are available.
If you own this model and would like to contribute images, submissions may be used with the original photographer’s permission.
Why Choose the Kubota KL285?
-
Proven Kubota diesel engine reliability
-
Available high-speed variant for efficient transport
-
Strong 4WD performance with compact dimensions
-
Suitable for farming, estate management, and utility work
