Iseki TPC213 Agricultural Crawler Tractor – Specifications & Overview
Overview
The Iseki TPC213 is a compact agricultural crawler tractor designed for stable operation on slopes, soft ground, and narrow farmland. As part of the TPC Series, it sits between the TPC183 and higher-output models, offering an excellent balance of power, size, and fuel efficiency.
Thanks to its crawler drive system and simple mechanical structure, the TPC213 is well-suited for orchards, vegetable fields, terraced land, and precision agricultural work where traction and stability are essential.
Produced from 2019 onward, this model reflects Iseki’s long tradition of building durable and easy-to-maintain agricultural machinery for professional farmers worldwide.
Engine
| Item | Specification |
|---|---|
| Engine model | Iseki diesel engine |
| Engine type | 4-stroke, water-cooled |
| Cylinders | 3 |
| Displacement | 1.1 L |
| Rated engine power | 20.7 hp (15.4 kW) |
| Fuel type | Diesel |
| Fuel tank capacity | 21.2 L (5.6 gal) |
The 1.1-liter diesel engine delivers smooth and reliable power while maintaining low fuel consumption, making it ideal for long working hours in agricultural environments.
Transmission
| Item | Specification |
|---|---|
| Transmission type | Mechanical |
| Gears | 8-speed shuttle |
| Drive system | Crawler (tracked) |
The 8-speed shuttle transmission allows precise speed control in both forward and reverse, which is especially useful for repetitive field tasks and confined working areas.
Power & Safety
| Item | Specification |
|---|---|
| Engine power | 20.7 hp |
| Drive | Crawler |
| ROPS | Two-post ROPS (Roll-Over Protective Structure) |
The crawler drive provides exceptional traction and minimizes ground pressure, improving safety and productivity on uneven or wet terrain.
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| Rear PTO type | 540 (1.375 in) |
| PTO engine speed | 468 @ 2500 rpm |
| 555 @ 2500 rpm | |
| 651 @ 2500 rpm |
The rear PTO supports a variety of agricultural implements, enabling the TPC213 to handle tasks such as tilling, cultivation, and specialized crawler-tractor attachments.
Dimensions & Tracks
| Item | Specification |
|---|---|
| Operating weight | 959 kg (2,116 lbs) |
| Undercarriage | Crawler tracks |
The robust tracked undercarriage ensures excellent stability and consistent performance, even in challenging field conditions.
Electrical
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery voltage | 12 V |
Photos
Currently, no official photos of the Iseki TPC213 are publicly available.
However, the tractor shares the same design philosophy and layout as other models in the TPC Series, featuring a compact body, low center of gravity, and durable crawler system optimized for agricultural use.
