New Holland T4040V Ultra-Narrow Tractor – Specifications & Overview
Overview
| Item | Details |
|---|---|
| Model | New Holland T4040V |
| Series | T4000V Series |
| Type | Ultra-Narrow Utility Tractor |
| Manufacturer | New Holland |
| Production Years | 2008 – 2011 |
| Built In | Jesi, Italy |
| Platform | ROPS |
| Cab | Optional (with heater & air conditioning) |
Series Map
| Model | Engine Power |
|---|---|
| T4030V | 76.0 hp |
| T4040V | 87.0 hp |
| T4050V | 95.0 hp |
Variants
| Variant | Description |
|---|---|
| T4040 | Conventional chassis |
| T4040F | Narrow chassis |
| T4040V | Ultra-narrow chassis |
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | New Holland |
| Engine Type | Diesel |
| Displacement | 3.2 L |
| Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Fuel Tank Capacity | 19.3 gal (73.1 L) |
Power
| Category | Output |
|---|---|
| Engine Power (Gross) | 87 hp (64.9 kW) |
| PTO Power (Claimed) | 72 hp (53.7 kW) |
Transmission
| Type | Details |
|---|---|
| Mechanical Shuttle | 16-speed |
| Power Shuttle | 16-speed |
Mechanical
| Item | Specification |
|---|---|
| Drive (Standard) | 2WD (4×2) |
| Drive (Optional) | MFWD 4WD (4×4) |
| Steering | Hydrostatic power |
| Brakes | Hydraulic wet disc |
Hydraulics
| Item | Specification |
|---|---|
| System Type | Open center |
| Hydraulic Pressure | 2,755 psi (190 bar) |
| Valves | 2 – 3 |
| Pump Flow | 17.2 gpm (65.1 L/min) |
| Steering Flow | 9.2 gpm (34.8 L/min) |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| Rear PTO Type | 540 / 1000 rpm |
| PTO Engagement | Independent |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase (2WD) | 81.9 in (208 cm) |
| Wheelbase (4WD) | 82.4 in (209 cm) |
| Operating Weight | 5,108 – 5,975 lbs |
Electrical System
| Item | Specification |
|---|---|
| Charging System | Alternator |
| Charging Output | 120 amps |
| Battery Voltage | 12 V |
| Battery CCA | 800 |
Photos
No official photos of the New Holland T4040V are currently available.
Why Choose the New Holland T4040V?
The New Holland T4040V is designed for professional vineyard and orchard operations requiring maximum power in an ultra-narrow format. With a strong 87 HP diesel engine, high-flow hydraulics, and optional MFWD, it delivers excellent traction, stability, and productivity in tight row spacing. Built in Italy, the T4040V combines precision engineering with long-term reliability for specialty farming worldwide.
