Iseki TPC153 Agricultural Crawler Tractor – Specifications & Overview
Overview
| Item | Details |
|---|---|
| Model | Iseki TPC153 |
| Series | TPC Series |
| Type | Agricultural Crawler Tractor |
| Manufacturer | Iseki |
| Production Years | 2019 – |
| Drive System | Crawler (Track drive) |
| Safety | Two-post ROPS |
| Intended Use | Paddy fields, soft ground, slopes, specialty agriculture |
The Iseki TPC153 is a modern crawler tractor that evolved from the earlier TPC15 series. It is designed for stable operation in wet, muddy, or uneven fields, offering improved control and efficiency for professional agricultural use.
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Iseki |
| Engine Type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 0.8 L |
| Rated Engine Power | 15.4 hp (11.5 kW) |
| Fuel Tank Capacity | 3.4 gal (12.9 L) |
The compact 0.8-liter diesel engine delivers reliable output with excellent fuel efficiency, suitable for long working hours in crawler applications.
Power Output
| Item | Output |
|---|---|
| Engine Power | 15.4 hp (11.5 kW) |
Transmission
| Item | Specification |
|---|---|
| Transmission Type | 8-speed shuttle |
| Drive | Crawler (tracks) |
The shuttle transmission allows smooth forward and reverse operation, improving productivity during repetitive field tasks.
PTO (Power Take-Off)
| Item | Specification |
|---|---|
| Rear PTO Type | 540 rpm (1.375 in) |
| PTO Speed @ Engine RPM | 466 rpm @ 2,500 rpm |
| 666 rpm @ 2,500 rpm |
The rear PTO supports a wide range of implements used in crawler tractor operations.
Dimensions & Tracks
| Item | Specification |
|---|---|
| Operating Weight | 1,720 lbs (780 kg) |
| Track Type | Rubber crawler tracks |
The crawler system provides excellent traction, low ground pressure, and superior stability compared to wheeled tractors.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery Voltage | 12 V |
Photos
Currently, no official photos of the Iseki TPC153 are available.
