Iseki TM3215 Compact Utility Tractor – Specifications & Overview
Overview
| Item | Details |
|---|---|
| Model | Iseki TM3215 |
| Series | TM Series |
| Type | Compact Utility Tractor |
| Manufacturer | Iseki |
| Production Years | 2010 – |
| Drive System | 4WD (Four-wheel drive) |
| Steering | Hydrostatic power steering |
| Differential Lock | Standard |
| Brakes | Wet disc |
| Safety | Two-post ROPS |
| Intended Use | Farming, landscaping, mowing, utility work |
The Iseki TM3215 is a compact utility tractor designed for durability and versatility. With modern transmission options and strong hydraulic performance, it suits a wide range of agricultural and maintenance applications.
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Iseki |
| Engine Type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 1.1 L |
| Rated Engine Power | 19.2 hp (14.3 kW) |
| Fuel Tank Capacity | 7.4 gal (28.0 L) |
This fuel-efficient diesel engine delivers stable power and long operating time, ideal for daily farm use.
Power Output
| Item | Output |
|---|---|
| Engine Power | 19.2 hp (14.3 kW) |
Transmission
| Item | Specification |
|---|---|
| Transmission Options | 8-speed gear / Hydrostatic |
| Drive | 4WD |
| Differential Lock | Standard |
Operators can choose between a traditional 8-speed gear transmission or a smooth hydrostatic transmission, depending on work style and preference.
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic Pump Flow | 5.31 gpm (20.1 L/min) |
PTO (Power Take-Off)
| Item | Specification |
|---|---|
| Rear PTO | Independent (hydro) |
| PTO Clutch | Mechanical (gear) / Electro-hydraulic (hydro) |
| Rear PTO Speed | 540 rpm (1.375 in) |
| Engine RPM @ PTO (gear) | 545 rpm @ 2,500 engine rpm |
| Engine RPM @ PTO (hydro) | 550 rpm @ 2,500 engine rpm |
| Mid PTO Speed | 2,000 rpm |
| Engine RPM @ Mid PTO (gear) | 2,032 rpm @ 2,500 engine rpm |
| Engine RPM @ Mid PTO (hydro) | 2,047 rpm @ 2,500 engine rpm |
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
| Hitch Control | Position control |
| Rear Lift Capacity | 1,323 lbs (600 kg) |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 61.42 in (156 cm) |
| Operating Weight | 1,808 – 1,830 lbs (approx.) |
| Front Tire Size | 6-12 |
| Rear Tire Size | 9.5-16 |
The slightly larger chassis compared to earlier TM models provides improved stability and lifting performance while remaining compact and easy to maneuver.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery Voltage | 12 V |
Photos
Currently, no official photos of the Iseki TM3215 are available.
Catalog-style images (white background, no people, 1880×800 format) can be prepared once a unit is photographed.
