Iseki TM3160 Sub-Compact Utility Tractor – Specifications & Overview
Overview
| Item | Details |
|---|---|
| Model | Iseki TM3160 |
| Series | TM Series |
| Type | Sub-Compact Utility Tractor |
| Manufacturer | Iseki |
| Production Years | 2004 – Unknown |
| Drive System | 4WD (Four-wheel drive) |
| Steering | Manual |
| Safety | ROPS (Roll-Over Protective Structure) |
| Intended Use | Small farms, gardening, mowing, light agricultural work |
The Iseki TM3160 is a reliable sub-compact utility tractor designed for light-duty agricultural and property maintenance tasks. Its simple mechanical structure and compact size make it easy to operate and maintain.
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Iseki |
| Engine Type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 0.9 L |
| Rated Engine Power | 15.3 hp (11.4 kW) |
| Fuel Tank Capacity | 3.6 gal (13.6 L) |
This fuel-efficient diesel engine provides stable power output, ideal for small-scale farming and daily utility work.
Power Output
| Item | Output |
|---|---|
| Engine Power | 15.3 hp (11.4 kW) |
| PTO Power (claimed) | 13.5 hp (10.1 kW) |
Transmission
| Item | Specification |
|---|---|
| Transmission Type | 6-speed gear |
| Drive | 4WD |
| Differential Lock | Standard |
| Brake Type | Mechanical wet disc |
The 6-speed gear transmission offers dependable control and durability, suitable for operators who prefer a straightforward mechanical drivetrain.
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic Pressure | 1,993 psi (137.4 bar) |
| Total Hydraulic Flow | 2.6 gpm (9.8 L/min) |
PTO (Power Take-Off)
| Item | Specification |
|---|---|
| Rear PTO Type | 585 rpm |
| Mid PTO Type | 2,000 rpm |
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category 0 |
| Rear Lift Capacity (at ends) | 1,058 lbs (479 kg) |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 53 in (134 cm) |
| Operating Weight | 1,312 lbs (595 kg) |
| Front Tire Size | 5-12 |
| Rear Tire Size | 8-16 |
The compact footprint allows easy maneuvering in confined areas such as orchards, gardens, and small plots.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 8.5 amps |
| Battery Voltage | 12 V |
| Battery CCA | 325 |
Photos
Currently, no official photos of the Iseki TM3160 are available.
Catalog-style images (white background, no people, 1880×800 format) can be prepared once a unit is photographed.
