Iseki TM223 Compact Utility Tractor – Specifications & Overview
Overview
| Item | Details |
|---|---|
| Model | Iseki TM223 |
| Series | TM Series |
| Type | Compact Utility Tractor |
| Manufacturer | Iseki |
| Production Years | Unknown – 2004 |
| Drive System | 4WD (Four-wheel drive) |
| Steering | Hydrostatic power steering |
| Intended Use | Farming, landscaping, mowing, light-duty work |
The Iseki TM223 is a compact utility tractor designed for versatility and ease of operation. With its hydrostatic transmission and four-wheel drive system, it delivers smooth control and reliable traction for a wide range of agricultural and property maintenance tasks.
Engine
| Item | Specification |
|---|---|
| Engine Manufacturer | Iseki |
| Engine Type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 1.1 L |
| Rated Engine Power | 22.5 hp (16.8 kW) |
| Fuel Tank Capacity | 6.1 gal (23.1 L) |
The 1.1-liter diesel engine provides dependable performance with excellent fuel efficiency, making the TM223 suitable for long working hours with low running costs.
Power Output
| Item | Output |
|---|---|
| Engine Power | 22.5 hp (16.8 kW) |
| PTO Power (claimed) | 18.5 hp (13.8 kW) |
Transmission
| Item | Specification |
|---|---|
| Transmission Type | Hydrostatic |
| Drive | 4WD |
| Brake Type | Mechanical dry shoe |
| Differential | Mechanical |
The hydrostatic transmission allows smooth speed control without shifting gears, ideal for operators who value precision and ease of use.
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic Type | Open center |
| System Pressure | 1,991 psi (137.3 bar) |
| Total Flow | 5.3 gpm (20.1 L/min) |
| Steering Flow | 2.6 gpm (9.8 L/min) |
PTO (Power Take-Off)
| Item | Specification |
|---|---|
| Rear PTO | Independent |
| Rear PTO Speed | 540 rpm |
| Mid PTO Speed | 2,000 rpm |
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
| Rear Lift Capacity (at ends) | 1,213 lbs (550 kg) |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 59.8 in (151 cm) |
| Operating Weight | 1,411 lbs (640 kg) |
| Front Tire Size | 5.00-12 |
| Rear Tire Size | 9.5-16 |
The compact size and lightweight design make the TM223 easy to maneuver in tight spaces while still providing sufficient stability for daily farm work.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 40 amps |
| Battery Voltage | 12 V |
| Battery CCA | 435 |
Attachments
Compatible attachments expand the versatility of the Iseki TM223:
| Attachment Type | Size |
|---|---|
| Front-mount mower deck | 51.2 in |
| Mid-mount mower deck | 54 in |
| Mid-mount mower deck | 60 in |
| Rear-mount mower deck | 42.1 in |
Photos
Currently, no official photos of the Iseki TM223 are available.
Catalog-style images (white background, no people) can be prepared once a unit is photographed.
