Kubota KB23X Tractor Specifications & Overview
Overview
The Kubota KB23X is a sub-compact utility tractor from the KB Kingbull Extra Series, produced between 2009 and 2014 for the Japanese domestic market.
As the upper model above the KB21X, the KB23X delivers the highest output in its class while preserving compact dimensions for orchards, greenhouses, and small farms.
With four-wheel drive, power steering, and an optional enclosed cab with air-conditioning, the KB23X combines power, comfort, and reliability—making it a strong candidate for export markets that demand durable tractors with low operating costs.
Engine
| Item | Specification |
|---|---|
| Manufacturer | Kubota |
| Engine type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 1.3 L |
| Rated power | 22.1 hp (16.5 kW) |
| Cooling system | Liquid-cooled |
| Fuel system | Mechanical diesel |
| Fuel tank (ROPS) | 7.1 gal (26.9 L) |
| Fuel tank (Cab) | 5.6 gal (21.2 L) |
The larger 1.3-liter Kubota diesel engine provides stronger torque and improved work capacity, ideal for PTO-intensive operations and heavier attachments.
Transmission
| Item | Specification |
|---|---|
| Transmission options | 9-speed / 36-speed power shift |
| Drive system | Four-wheel drive (4WD) |
| Steering | Power steering |
Multiple gear ranges enable precise speed control for tilling, mowing, transport, and PTO-driven implements.
Power & Mechanical
| Item | Specification |
|---|---|
| Engine output | 22.1 hp |
| Brakes | Mechanical wet disc brakes |
| ROPS | Two-post ROPS |
| Cab | Optional, with air-conditioning |
| Hitch category | Rear Type 0 |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO type | Rear PTO |
| PTO speed | 540 rpm |
| PTO shaft size | 1.375 in |
| PTO engine speeds | 530 / 799 / 1182 / −662 @ 2600 rpm |
Supports rotary tillers, mowers, sprayers, and other compact agricultural implements.
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase (ROPS) | 53.2 in (135 cm) |
| Wheelbase (Cab) | 53.7 in (136 cm) |
| Operating weight | 1,554 – 1,951 lbs |
| Front tires | 6.00-12 |
| Rear tires | 9.5-20 |
The heavier chassis and wider rear tires improve traction and stability, particularly during demanding PTO work.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery voltage | 12 V |
Variants
| Model | Description |
|---|---|
| KB23X | Wheeled tractor |
| KB23X-PC | Half-track version |
Photos
Official catalog photos of the Kubota KB23X are limited.
