Kubota KB16 Tractor Specifications & Overview
Overview
The Kubota KB16 is a sub-compact utility tractor from the KB Kingbull Series, produced between 2005 and 2007 for the Japanese domestic market.
Positioned between the KB18 and the later KB165, the KB16 is designed for users who require higher versatility and transmission flexibility while maintaining a compact footprint.
With multiple transmission options, four-wheel drive, and power steering as standard, the KB16 is well suited for small farms, orchards, greenhouse operations, and light-duty agricultural work in export markets.
Engine
| Item | Specification |
|---|---|
| Manufacturer | Kubota |
| Engine type | Diesel |
| Cylinders | 3-cylinder |
| Displacement | 0.9 L |
| Rated power | 15.8 hp (11.8 kW) |
| Fuel tank capacity | 7.1 gal (26.9 L) |
| Cooling system | Liquid-cooled |
| Fuel system | Mechanical diesel |
The 0.9-liter Kubota diesel engine delivers stable torque, excellent fuel efficiency, and long-term reliability—making it ideal for continuous light agricultural tasks.
Transmission
| Item | Specification |
|---|---|
| Transmission options | 9-speed / 36-speed power shift |
| Drive system | Four-wheel drive (4WD) |
| Steering | Power steering |
The wide transmission range allows precise speed selection for PTO work, field operations, and transport.
Power & Mechanical
| Item | Specification |
|---|---|
| Engine output | 15.8 hp |
| Brakes | Mechanical wet disc brakes |
| ROPS | Two-post ROPS |
| Hitch category | Rear Type 0 |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO type | Rear PTO |
| PTO speed | 540 rpm |
| PTO shaft size | 1.375 in |
| PTO engine speeds | 530 / 799 / 1182 / −662 @ 2600 rpm |
This PTO configuration supports a wide variety of compact implements such as rotary tillers, mowers, and sprayers.
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 53.2 in (135 cm) |
| Operating weight | 1,521 – 1,576 lbs |
| Front tires | 6.00-12 |
| Rear tires | 8.3-20 |
The longer wheelbase compared to JB-series models improves stability while maintaining compact maneuverability.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery voltage | 12 V |
Photos
Official catalog photos of the Kubota KB16 are limited.
