Kubota JB16 Sub-Compact Utility Tractor Specifications
EVERY FARM TRACTOR has been exporting reliable Japanese used tractors and agricultural machinery since 2006 to customers in more than 100 countries worldwide.
Below is a clear, inquiry-ready specification guide for the Kubota JB16, created to help global buyers easily understand this model and make confident inquiries.
Overview
| Item | Details |
|---|---|
| Model | Kubota JB16 |
| Series | JB Bullstar Series |
| Production Years | 2006 – 2008 |
| Manufacturer | Kubota |
| Category | Sub-Compact Utility Tractor |
| Drive System | Four-wheel drive (4WD) |
| Steering | Manual (Power steering optional) |
| Brakes | Wet disc |
| Safety | Two-post ROPS |
Series Map (Power Output)
JB14 (10.7 kW) / JB16 (12.1 kW) / JB18 (13.6 kW)
Successor series: JB17X (2009–2019)
Engine
| Item | Specification |
|---|---|
| Engine Type | Kubota diesel engine |
| Cylinders | 3-cylinder |
| Cooling | Liquid-cooled |
| Displacement | 1.0 L |
| Fuel Type | Diesel |
| Rated Engine Power | 16.2 hp (12.1 kW) |
| Fuel Tank Capacity | 3.7 gal (14.0 L) |
The 1.0-liter Kubota diesel engine delivers noticeably higher torque and power compared to smaller JB models, while maintaining excellent fuel efficiency and long-term durability.
Transmission
| Item | Specification |
|---|---|
| Transmission Type | Mechanical |
| Gears | 6-speed |
The proven 6-speed mechanical transmission provides reliable power delivery and straightforward maintenance, ideal for daily agricultural work.
Variants
| Model | Configuration |
|---|---|
| JB16 | Wheeled |
| JB16-PC | Half-track |
The half-track version improves traction and stability on soft soil, slopes, and uneven terrain.
Power & PTO
| Item | Specification |
|---|---|
| Hitch Type | Rear 3-point, Category 0 |
| PTO Location | Rear |
| PTO Speed | 540 rpm |
| PTO Shaft Size | 1.375 inch |
| PTO Ratios | 551:2600 / 967:2600 |
This PTO setup supports compact implements such as rotary tillers, mowers, and small spreaders, making the JB16 highly versatile for sub-compact applications.
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 50 in (127 cm) |
| Operating Weight | 1,301 lbs (590 kg) |
| Front Tires | 5.00-12 |
| Rear Tires | 8-18 |
The increased weight and larger rear tires improve traction, balance, and stability compared to smaller JB models.
Electrical System
| Item | Specification |
|---|---|
| Electrical System | 12 V |
| Ground | Negative |
Photos
Currently, no official public photos of the Kubota JB16 are available.
Actual unit photos and catalog-style images can be provided by EVERY FARM TRACTOR depending on stock availability.
Summary
The Kubota JB16 is one of the most powerful models in the JB Bullstar Series, offering a 16.2 hp diesel engine, 4WD capability, optional power steering, and a reliable mechanical transmission. It is well suited for orchards, greenhouses, landscaping, and small farms that require strong performance in a compact tractor.
EVERY FARM TRACTOR carefully inspects and exports tractors like the JB16 to ensure long-term reliability, transparency, and customer confidence worldwide.
