🚜 Massey Ferguson 394S Tractor Specifications & Overview
| Item | Details |
|---|---|
| Model | Massey Ferguson 394S |
| Series | 304 Specialty Series |
| Type | Orchard / Vineyard Tractor |
| Production Years | 1994 – 1999 |
| Manufacturer | Massey Ferguson |
| Built In | Italy |
| Original Price | USD 29,200 (1999) |
| Drive Options | 2WD / 4WD |
| Steering | Power steering |
| Brakes | Hydraulic wet disc brakes |
| ROPS / Cab | Two-post mid-mount ROPS, optional cab |
Series Map (Estimated Engine Power)
For comparison purposes only
| Model | Estimated Power |
|---|---|
| 384S | 72.2 hp* |
| 394S | 81.1 hp* |
| 3245 (successor) | 1999–2001 |
Variants
| Variant | Description |
|---|---|
| 394S | Narrow |
| 394GE | Low profile |
| 394HC | High clearance |
Engine
| Item | Specification |
|---|---|
| Engine Model | Perkins |
| Type | Diesel |
| Cylinders | 4 |
| Displacement | 4.1 L |
| Fuel Tank | 14.0 gal (53.0 L) |
Transmission
| Option | Description |
|---|---|
| 12-speed | Synchromesh |
| 12-speed | Shuttle |
| 24-speed | Creeper |
Power & PTO
| Measurement | Value |
|---|---|
| PTO Power (claimed) | 73 hp (54.4 kW) |
| PTO Type | Independent |
| PTO Speeds | 540 / 750 rpm |
| 540 / 1000 rpm | |
| Engine Speed @ 540 PTO | 1960 rpm |
Hydraulics
| Item | Specification |
|---|---|
| Rear Valves | 2 |
| Front Valves | 3 (optional) |
| Pump Flow | 11.2 gpm (42.4 L/min) |
Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category II / I |
| Rear Lift Capacity (ends) | 5,732 lbs (2,600 kg) |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase (2WD) | 81.5 in (207 cm) |
| Wheelbase (4WD) | 79.3 in (201 cm) |
| Operating Weight | 5,291 – 5,622 lbs |
| Front Tire | 7.5L-16 |
| Rear Tire (2WD) | 16.9-24 |
Electrical
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery Voltage | 12 V |
Attachments
| Attachment | Notes |
|---|---|
| Front-End Loader | Compatible |
Photos
No official photos are currently available for the Massey Ferguson 394S. This model is less commonly photographed due to its specialty orchard and vineyard configuration.
Why the Massey Ferguson 394S Is Ideal for Orchards & Vineyards
The Massey Ferguson 394S was designed specifically for narrow-row agriculture such as orchards and vineyards. Its compact width, multiple transmission choices including creeper gears, strong hydraulics, and reliable Perkins diesel engine make it well suited for precision work where maneuverability and control are critical.
