New Holland T8.380 – Specifications & Overview
The New Holland T8.380 is a high-horsepower row-crop tractor introduced in 2015 as part of the advanced T8 Series lineup. Designed for large-scale, high-output farming, it delivers exceptional engine performance, strong PTO output, and flexible transmission choices for demanding field and transport operations.
Manufactured in Racine, Wisconsin (USA) by New Holland, a part of CNH, the T8.380 was originally priced at approximately USD 305,073 in 2016 (PowerShift version). It is available in both wheeled and SmartTrax half-track configurations, making it suitable for a wide range of soil and traction conditions.
Key Information
| Item | Details |
|---|---|
| Model | New Holland T8.380 |
| Production Years | 2015 – present |
| Series | T8 Series |
| Tractor Type | Row-Crop Tractor |
| Manufacturing Location | Racine, Wisconsin, USA |
| Drive | 4WD |
| Variants | Wheeled / SmartTrax (half-track) |
| Similar Model | Case IH Magnum 310 |
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | FPT (Fiat Powertrain Technologies) |
| Engine Model | FPT 8.7L |
| Configuration | 6-cylinder diesel |
| Displacement | 8.7 L |
| Emissions System | SCR with DEF |
| Fuel Tank (CVT) | 163 gal (617.0 L) |
| Fuel Tank (PowerShift) | 179 gal (677.5 L) |
| DEF Capacity | 26 gal (98.4 L) |
Engine & PTO Power
| Measurement | Output |
|---|---|
| Gross Engine Power | 311 hp (231.9 kW) |
| Maximum Engine Power | 382 hp (284.9 kW) |
| PTO Power (claimed) | 265 hp (197.6 kW) |
| PTO Power (tested) | 313.71 hp (233.9 kW) |
| Drawbar Power (tested) | 234.51 hp (174.9 kW) |
Transmission
| Option | Description |
|---|---|
| 18-Speed | Full PowerShift |
| CVT | Continuously Variable Transmission |
| 23-Speed | PowerShift Creeper |
The wide transmission lineup allows operators to optimize performance for heavy tillage, precision fieldwork, or long-distance transport.
Hydraulics
| Specification | Details |
|---|---|
| System Type | Closed Center Pressure-Flow Compensating (PFC) |
| Remote Valves | 4 – 5 |
| Standard Pump Flow | 44 gpm (166.5 L/min) |
| High-Flow Option | 75 gpm (283.9 L/min) |
Hitch & Drawbar
| Item | Specification |
|---|---|
| Rear Hitch Type | Category III / IIIN / IVN |
| Hitch Control | Electronic lower-link draft sensing |
| Rear Lift Capacity | 15,900 – 19,500 lbs (7,212 – 8,845 kg) |
| Drawbar | Category 3 |
| Optional Drawbar | Category 4 |
Power Take-Off (PTO)
| Item | Details |
|---|---|
| Rear PTO | Independent |
| Rear PTO Types | 1000 (1.75 in) |
| Optional PTO | 540 / 1000 (1.375 in) |
| Engine RPM @ 540 | 1800 rpm |
| Engine RPM @ 1000 | 1800 rpm |
| Front PTO | Independent (optional) |
| Front PTO Speed | 1000 rpm |
Dimensions & Weight
| Specification | Value |
|---|---|
| Wheelbase (PowerShift) | 136 in (345 cm) |
| Wheelbase (CVT) | 138 in (350 cm) |
| Operating Weight | 22,487 lbs (10,200 kg) |
| Front Tires | 420/85R34 |
| Rear Tires | 480/80R50 |
Cab & Operator Comfort
-
Enclosed cab with air-conditioning (standard)
-
Optional Comfort Ride™ cab suspension
-
IntelliSteer™ ready for auto-guidance
-
Power steering and wet disc brakes
-
Designed for long working hours and reduced fatigue
Attachments
| Attachment | Availability |
|---|---|
| Front-End Loader | Compatible |
| Front Hitch & PTO | Optional |
| Heavy Implements | Plows, cultivators, planters, grain carts |
Electrical System
| Item | Specification |
|---|---|
| System Voltage | 12 V |
| Ground | Negative |
| Alternator Output | 200 A |
| Batteries | 2 × 12 V |
Serial Number Reference
| Year | Serial Prefix |
|---|---|
| 2015 | ZER |
| 2016 | ZFR |
| 2017 | ZGR |
| 2018 | ZHR |
| 2019 | ZJR |
| 2020 | ZKR |
| 2021 | ZLR |
Tests & Performance
Performance testing confirms the T8.380’s excellent drawbar efficiency and strong PTO output, making it suitable for the largest modern implements and high-demand PTO-driven machinery.
Summary
The New Holland T8.380 is a powerful, export-ready row-crop tractor that combines a proven FPT 8.7L engine with advanced transmission options and high-capacity hydraulics. For professional farmers and contractors seeking flexibility, traction options, and top-tier horsepower, the T8.380 stands out as one of the most capable models in the New Holland T8 Series.
