New Holland T8.275 – Specifications & Overview
The New Holland T8.275 is a heavy-duty row-crop tractor from the T8 Series, engineered for high-demand field operations and large implements. Produced between 2011 and 2014, this model bridges the gap between versatile row-crop capability and true high-horsepower performance.
Built in Racine, Wisconsin (USA) by New Holland, part of CNH Industrial, the T8.275 is well known for its robust drivetrain, powerful PTO output, and reliable FPT engine platform.
Key Information
| Item | Details |
|---|---|
| Model | New Holland T8.275 |
| Production Years | 2011 – 2014 |
| Model Years | 2011 – 2012 |
| Series | T8 Series |
| Tractor Type | Row-Crop Tractor |
| Manufacturing Location | Racine, Wisconsin, USA |
| Drive | 4WD |
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | FPT (Fiat Powertrain Technologies) |
| Engine Model | FPT 8.7L |
| Configuration | 6-cylinder diesel |
| Displacement | 8.7 L |
| Emissions System | SCR with DEF |
| Fuel Tank Capacity | 168 gal (635.9 L) |
| DEF Capacity | 24 gal (90.8 L) |
Engine & PTO Power
| Measurement | Output |
|---|---|
| Gross Engine Power | 235 hp (175.2 kW) |
| Maximum Engine Power | 258 hp (192.4 kW) |
| PTO Power (claimed) | 195 hp (145.4 kW) |
| PTO Power (tested) | 233.95 hp (174.5 kW) |
| Drawbar Power (tested) | 172.71 hp (128.8 kW) |
Transmission
| Option | Description |
|---|---|
| 19-Speed | Full Power Shift |
| 18-Speed | Full Power Shift |
| 23-Speed | Creeper transmission |
These transmission options allow the T8.275 to be configured for heavy tillage, controlled low-speed work, or high-efficiency transport.
Hydraulics
| Specification | Details |
|---|---|
| System Type | Closed Center Load Sensing (CCLS) |
| Rear Remote Valves | 4 – 6 |
| Standard Pump Flow | 35 gpm (132.5 L/min) |
| Total Flow | 42.5 gpm (160.9 L/min) |
| MegaFlow Option | 72.3 gpm (273.7 L/min) |
Hitch & Lift Capacity
| Item | Specification |
|---|---|
| Rear Hitch Type | Category III / IIIN |
| Rear Lift Capacity | 14,080 lbs (6,386 kg) |
| Optional Rear Lift | 16,375 lbs (7,427 kg) |
| Front Hitch | Optional |
Power Take-Off (PTO)
| Item | Details |
|---|---|
| Rear PTO | Independent |
| Rear PTO Types | 1000 (1.75 in) |
| Optional PTO | 540 / 1000 (1.375 in) |
| Engine RPM @ 540 | 1804 rpm |
| Engine RPM @ 1000 | 1804 rpm |
| Front PTO | Independent (optional) |
| Front PTO Speed | 1000 rpm |
Dimensions & Weight
| Specification | Value |
|---|---|
| Wheelbase | 135.8 in (344 cm) |
| Operating Weight | 23,862 – 24,662 lbs |
| Tire Options | Multiple agricultural configurations |
Cab & Operator Environment
-
Enclosed cab (standard)
-
Power steering
-
Hydraulic wet disc brakes
-
Designed for long working hours and reduced operator fatigue
Electrical System
| Item | Specification |
|---|---|
| System Voltage | 12 V |
| Ground | Negative |
| Alternator Output | 200 A |
| Batteries | 2 × 12 V |
Tests & Performance
Independent performance testing shows strong drawbar efficiency and impressive PTO output, confirming the T8.275’s suitability for large tillage tools, grain carts, and high-demand PTO-driven equipment.
Summary
The New Holland T8.275 delivers dependable high-horsepower performance with a proven FPT 8.7L engine and multiple transmission options. Built for large-scale farming operations, it remains a popular choice in the used tractor market for buyers seeking durability, power, and versatility in a row-crop tractor.
For global export markets, the T8.275 continues to stand out as a reliable and cost-effective high-horsepower solution in the New Holland T8 Series.
