Massey Ferguson 374S – Overview
The Massey Ferguson 374S is a powerful orchard and vineyard tractor from the 304 Specialty Series, designed for high-output work in narrow rows, vineyards, orchards, and specialty crop farms.
Produced from 1994 to 1999 and built in Italy, the MF 374S delivers increased PTO power, excellent hydraulic performance, and compact dimensions while maintaining stability and durability.
This model sits above the 364S and is well suited for heavier implements and front-mounted attachments in confined agricultural environments.
Production Information
| Item | Details |
|---|---|
| Model | Massey Ferguson 374S |
| Series | 304 Specialty Series |
| Production Years | 1994 – 1999 |
| Tractor Type | Orchard / Vineyard Tractor |
| Manufacturer | Massey Ferguson |
| Built In | Italy |
| Original Price | USD 26,500 (1999) |
Series Map (Estimated Engine Power*)
| Model | Estimated Power* |
|---|---|
| 364S | 55.6 hp* |
| 374S | 63.3 hp* |
| 384S | 72.2 hp* |
*Estimated engine power for comparison only.
Variants
| Variant | Description |
|---|---|
| 374S | Narrow |
| 374F | Narrow |
| 374GE | Low-profile |
| 374V | Ultra-narrow (vineyard use) |
Engine Specifications
| Item | Specification |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Type | Diesel |
| Displacement | 3.9 L |
| Cylinders | 4 |
| Fuel Tank Capacity | 14 gal (53.0 L) |
Power Output
| Item | Output |
|---|---|
| PTO Power (claimed) | 57 hp |
| PTO Power | 42.5 kW |
Transmission Options
| Transmission | Details |
|---|---|
| Synchromesh | 12-speed |
| Shuttle | 12-speed shuttle |
| Creeper | 24-speed creeper |
These transmission options allow precise speed control for spraying, harvesting, mowing, and low-speed vineyard operations.
Mechanical Features
| Item | Specification |
|---|---|
| Drive | 2WD or 4WD |
| Differential Lock | Electro-hydraulic (front & rear) |
| Steering | Power steering |
| Brakes | Hydraulic wet disc |
| ROPS | Two-post mid-mount |
| Cab | Available |
Hydraulic System
| Item | Specification |
|---|---|
| Rear Valves | 2 |
| Front Valves | 3 (optional) |
| Pump Flow | 11.2 gpm (42.4 L/min) |
| Optional Flow | 14.3 gpm (54.1 L/min) |
Hitch & Lifting Capacity
| Item | Specification |
|---|---|
| Rear Hitch Type | II / I |
| Rear Lift Capacity (ends) | 5,732 lbs (2,600 kg) |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO Type | Independent |
| Rear PTO Speeds | 540 / 750 rpm |
| Optional PTO | 540 / 1000 rpm |
| Engine Speed @ 540 PTO | 1,960 rpm |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase (2WD) | 81.5 in (207 cm) |
| Wheelbase (4WD) | 79.3 in (201 cm) |
| Operating Weight | 5,181 – 5,512 lbs |
| Front Tires | 7.5L-15 |
| Rear Tires (2WD) | 14.9-24 |
Attachments
| Attachment | Compatibility |
|---|---|
| Front-End Loader | Yes |
The MF 374S supports front-end loaders and specialty orchard implements, supported by its strong hydraulics and stable chassis.
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Battery Voltage | 12 V |
Photos
Official reference photos of the Massey Ferguson 374S are limited.
The images shown above represent 304 Specialty Series orchard and vineyard tractors, illustrating typical cab design, narrow-track layout, and proportions.
Why the Massey Ferguson 374S Excels in Specialty Farming
-
High-output Perkins 3.9L 4-cylinder diesel engine
-
Narrow, low-profile variants for vineyards and orchards
-
Strong hydraulics for sprayers, mowers, and loaders
-
Italian-built precision with Massey Ferguson durability
The Massey Ferguson 374S remains an excellent choice for farmers who require power, precision, and reliability in orchard and vineyard operations across global markets.
