Farmers searching for a Used Kubota Tractor often compare other reliable high-horsepower machines.
Among them, the Ford TW-25 is well known for its strong engine, stable performance, and long service life.
Since 2006, EVERY FARM TRACTOR has exported Japanese used tractors and agricultural machinery to more than 100 countries, helping farmers worldwide secure dependable equipment.
Overview
| Item | Details |
|---|---|
| Model | Ford TW-25 |
| Production Years | 1983 – 1989 |
| Series | TW Series |
| Tractor Type | Row-Crop Tractor |
| Manufacturer | Ford |
| Manufacturing Location | Antwerp, Belgium |
The Ford TW-25 sits between the TW-15 and TW-35.
Therefore, it offers a balanced combination of power, size, and versatility for large-scale farming.
Engine
| Item | Specification |
|---|---|
| Engine Model | Ford Diesel |
| Engine Type | 6-cylinder diesel |
| Displacement | 6.6 L |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 75 gal / 283.9 L |
| Series II Fuel Capacity | 100 gal / 378.5 L |
This proven 6.6-liter diesel engine provides strong torque at low RPM.
As a result, it performs efficiently in plowing, tillage, and heavy PTO operations.
Power Performance
| Measurement | Output |
|---|---|
| Engine Power (Gross) | 160 hp / 119.3 kW |
| Engine Power (Net) | 156 hp / 116.3 kW |
| PTO Power (Claimed) | 140 hp / 104.4 kW |
| PTO Power (Tested) | 140.7 hp / 104.9 kW |
| Drawbar Power (Tested) | 124.8 hp / 93.1 kW |
Thanks to its high PTO output, the Ford TW-25 handles large implements smoothly.
Transmission
| Option | Details |
|---|---|
| Standard Transmission | 16-speed partial power shift |
| Optional Transmission | 24-speed |
Smooth shifting improves productivity.
Moreover, the power shift design helps maintain traction under load.
Mechanical Features
| Feature | Specification |
|---|---|
| Drive Type | 2WD or 4WD |
| Differential Lock | Hydraulic rear |
| Steering | Power steering |
| Brakes | Hydraulic wet disc |
| ROPS | Standard |
| Cab | Optional |
These features improve operator control, safety, and comfort during long workdays.
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic Type | Open center |
| Hydraulic Capacity | 18.25 gal / 69.1 L |
| System Pressure | 2500 psi / 172.4 bar |
| Valves | 2 |
| Pump Flow | 15.3 gpm / 57.9 lpm |
| Series II Pump Flow | 23.8 gpm / 90.1 lpm |
| Total Flow | 27.5 gpm / 104.1 lpm |
| Steering Flow | 4.2 gpm / 15.9 lpm |
High hydraulic flow ensures stable operation of loaders and implements.
3-Point Hitch & PTO
Rear Hitch
| Item | Specification |
|---|---|
| Hitch Category | Category II |
| Optional Hitch | Category III |
| Control System | Position control & draft sensing |
| Lift Capacity (24” / 610 mm) | 7,150 lbs / 3,243 kg |
| Max Lift (Optional) | 9,450 lbs / 4,286 kg |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO Type | Independent |
| Rear PTO Speed | 540 / 1000 RPM |
| Engine RPM @ 540 | 1861 RPM |
| Engine RPM @ 1000 | 1918 RPM |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase (2WD) | 108 in / 274 cm |
| Wheelbase (4WD) | 110.7 in / 281 cm |
| Operating Weight | 12,267 – 15,500 lbs |
| Front Tire | 11.00-16 |
| Rear Tire | 18.4-38 |
The long wheelbase improves stability.
Consequently, field operations remain smooth even with heavy equipment.
Attachments
| Available Attachments |
|---|
| Front-end loader |
The TW-25 supports common agricultural attachments, making it highly versatile.
Serial Number Location
| Location |
|---|
| Under forward right grill panel |
| Year | Serial Number Start |
|---|---|
| 1983 | C694500 |
| 1984 | C707400 |
| 1985 | C732600 |
| 1986 | A915854 |
| 1987 | A917560 |
| 1988 | A919438 |
| 1989 | A922535 |
| 1990 | A925099 |
Why Choose a Used Ford TW-25 from EVERY FARM TRACTOR
Many buyers searching for a Used Kubota Tractor also compare Ford TW-series tractors.
The Ford TW-25 offers excellent value, strong horsepower, and proven durability.
In addition, EVERY FARM TRACTOR provides:
-
Accurate tractor information
-
Careful inspection before export
-
Secure international shipping
-
Clear communication from inquiry to delivery
Worldwide Export by EVERY FARM TRACTOR
EVERY FARM TRACTOR exports Japanese used tractors and agricultural machinery to more than 100 countries.
If you are looking for a powerful and dependable used tractor, the Ford TW-25 is a smart choice.
