The Ford FW-40 is a high-horsepower four-wheel-drive (4WD) articulated tractor produced from 1977 to 1979 as part of the Ford FW Series.
It was built for large-scale farming operations that demand strong drawbar power, reliable traction, and long working hours.
While many buyers begin their online search with a Used Kubota Tractor, experienced operators often look for more powerful machines.
Therefore, the Ford FW-40 remains a popular choice in the global used tractor market.
EVERY FARM TRACTOR exports this model to customers worldwide who require proven heavy-duty performance.
Production & Manufacturer
| Item | Details |
|---|---|
| Model | Ford FW-40 |
| Production Years | 1977 – 1979 |
| Series | FW Series |
| Tractor Type | Four-wheel Drive (4WD) Tractor |
| Distributor | Ford |
| Manufacturer | Steiger |
| Built In | Fargo, North Dakota, USA |
| Original Price | USD 66,572 (1979) |
Engine Specifications
The Ford FW-40 is equipped with a large Cummins diesel engine designed for heavy agricultural workloads.
As a result, it delivers excellent torque and long-term durability.
| Item | Specification |
|---|---|
| Engine Manufacturer | Cummins |
| Engine Type | Diesel |
| Displacement | 14.8 L |
| Cylinders | 8-cylinder |
| Aspiration | Naturally Aspirated |
Engine Highlights
-
High torque for deep tillage
-
Proven Cummins reliability
-
Designed for continuous heavy operation
Power & Performance
| Measurement | Output |
|---|---|
| Engine Power (gross) | 295 hp / 220.0 kW |
| Drawbar Power (claimed) | 230 hp / 171.5 kW |
| PTO Power (540 RPM) | 57 hp / 42.5 kW |
| PTO Power (1000 RPM) | 105 hp / 78.3 kW |
| Drawbar Power (tested) | 227.48 hp / 169.6 kW |
Because of this power level, the FW-40 easily handles large implements and wide field equipment.
Transmission
| Item | Specification |
|---|---|
| Transmission Options | 10-speed / 20-speed |
| Drive System | Full-time 4WD |
| Steering | Articulated Power Steering |
| Final Drives | Outboard Planetary |
This transmission system allows smooth power delivery under load.
Therefore, operators can maintain efficiency even in difficult soil conditions.
Hydraulics System
| Item | Specification |
|---|---|
| Hydraulic Type | Open Center |
| Capacity | 25 gal (94.6 L) |
| System Pressure | 2,250 psi (155.1 bar) |
| Control Valves | 4 or 5 |
| Pump Flow | 30.1 gpm (113.9 lpm) |
| SCV Flow | 20 gpm (75.7 lpm) |
This hydraulic setup supports modern heavy-duty agricultural implements.
PTO & Hitch
| Item | Details |
|---|---|
| Rear PTO | Independent |
| PTO Speeds | 540 / 1000 RPM |
| Rear Hitch Type | Type III |
| Rear Lift Capacity (24 in) | 12,500 lbs (5,670 kg) |
Dimensions & Tires
| Item | Measurement |
|---|---|
| Wheelbase | 132.5 in (336 cm) |
| Operating Weight | 30,630 lbs (13,893 kg) |
| Front Tires | 18.4-38 |
| Rear Tires | 18.4-38 |
Because of its wide stance and balanced weight, the FW-40 offers excellent traction and stability in the field.
Fuel & Capacity
| Item | Capacity |
|---|---|
| Fuel Tank | 225 gal (851.6 L) |
| Hydraulic System | 25 gal (94.6 L) |
Electrical System
| Item | Specification |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 90 amps |
| Batteries | 4 |
| Battery Voltage | 12 V |
Operator Comfort & Mechanical Features
-
Full-time four-wheel drive
-
Articulated steering for smooth turning
-
Hydraulic dry disc brakes
-
Enclosed cab with air-conditioning as standard
As a result, operators can work comfortably even during long farming seasons.
Why Global Buyers Choose the Ford FW-40
-
Very high horsepower for large-scale agriculture
-
Durable Cummins diesel engine
-
Strong hydraulic and PTO performance
-
Powerful option beyond a Used Kubota Tractor
Therefore, the FW-40 remains in demand across North America, Australia, Africa, and South America.
