Kubota GL260 Compact Utility Tractor
Overview
The Kubota GL260 is a compact utility tractor produced from 1993 to 1995, positioned above the GL240 within Kubota’s durable GL Series.
Manufactured in Japan, the GL260 delivers higher engine output, strong rear lift capacity, and excellent traction, making it suitable for heavier farming operations while maintaining compact usability.
This model is especially valued in international export markets due to its simple mechanical construction, reliable diesel engine, and compatibility with larger implements compared to lower GL models.
Production Information
| Item | Details |
|---|---|
| Manufacturer | Kubota |
| Series | GL Series |
| Model | GL260 |
| Production Years | 1993 – 1995 |
| Tractor Type | Compact Utility Tractor |
| Country of Origin | Japan |
Variants
| Variant | Configuration |
|---|---|
| GL260 | ROPS |
| GL260Q | Cab |
| GL260J | Large wheel specification |
Engine
The Kubota GL260 is equipped with a powerful Kubota diesel engine that offers increased output and torque for demanding agricultural tasks.
| Item | Specification |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | Diesel |
| Cylinders | 3 |
| Displacement | 1.5 L |
| Rated Engine Power | 25.6 hp (19.1 kW) |
| PTO Power (claimed) | 24.0 hp (17.9 kW) |
| Cooling System | Liquid-cooled |
| Fuel Tank Capacity | 7.1 gal (26.9 L) |
Engine Highlights
-
High output within the GL Series
-
Strong torque for tilling and hauling
-
Proven durability in hot and dusty climates
Transmission
The GL260 offers flexible transmission options to suit various field conditions and operator preferences.
| Transmission Type | Details |
|---|---|
| Gear Transmission | 16-speed manual |
| Power Shift | 16-speed power shift |
Transmission Features
-
Wide speed range for heavy-duty work
-
Smooth shifting under load
-
Durable gearbox design for long service life
Power & Mechanical Features
| Item | Specification |
|---|---|
| Drive System | Four-wheel drive (4WD) |
| Steering | Power steering |
| Brakes | Mechanical wet disc brakes |
| ROPS | Two-post ROPS |
| Cab Option | Optional (GL260Q) |
Hydraulics
The GL260 features a strong hydraulic system, enabling it to handle heavier rear-mounted implements.
| Item | Specification |
|---|---|
| Hydraulic Pump Flow | 5.6 gpm (21.2 L/min) |
| Rear Lift Capacity | 2,061 lb (934 kg) |
PTO (Power Take-Off)
The PTO system provides multiple speed options to support a wide range of agricultural implements.
| Item | Specification |
|---|---|
| PTO Type | Rear |
| PTO Speeds (RPM) | 568 / 803 / 985 / 1304 |
| PTO Shaft Size | 1.375 inch |
Hitch System
| Item | Specification |
|---|---|
| Rear Hitch Type | Category I |
Compatible implements include:
-
Rotary tillers
-
Plows
-
Harrows
-
Grass cutters
-
Trailers
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 64.8 in (164 cm) |
| Operating Weight | 2,601 – 2,888 lb |
| Front Tire Size | 7-16 |
| Rear Tire Size | 11.2-24 |
Electrical System
| Item | Specification |
|---|---|
| Electrical Ground | Negative |
| Battery Voltage | 12 V |
Photos
Currently, official photos of the Kubota GL260 are limited.
Actual appearance may vary depending on configuration and optional equipment.
Why Choose the Kubota GL260?
-
Built in Japan with trusted Kubota engineering
-
High power output and strong rear lift capacity
-
4WD with excellent traction for heavy tasks
-
Suitable for larger implements than GL240 / GL241
-
Strong demand in global export markets
