Massey Ferguson 293 Overview
| Item | Details |
|---|---|
| Model | Massey Ferguson 293 |
| Production years | 1983 – 1987 |
| Manufacturer | Massey Ferguson |
| Drive | 4×2 (2WD), optional 4×4 MFWD (4WD) |
| Steering | Hydrostatic power steering |
| Brakes | Wet disc brakes |
The Massey Ferguson 293 is a practical mid-power tractor built for reliable day-to-day field work. Its simple mechanical layout and widely supported Perkins engine make it popular in many export markets.
Engine
| Item | Specification |
|---|---|
| Engine make/model | Perkins A4.248 |
| Fuel type | Diesel |
| Cylinders | 4-cylinder |
| Displacement | 4.1 L (248.0 cu in) |
| Bore × Stroke | 3.975 × 5.00 in (101 × 127 mm) |
| Engine power | 80 hp (59.7 kW) |
| Rated RPM | 2200 rpm |
| Torque | 214.6 lb-ft (291.0 Nm) @ 1400 rpm |
| Fuel tank | 16.1 gal (60.9 L) |
Transmission
| Item | Specification |
|---|---|
| Transmission | 12-speed |
Hydraulics & 3-Point Hitch
| Item | Specification |
|---|---|
| Hydraulic total flow | 9.5 gpm (36.0 L/min) |
| Rear lift capacity | 5,843 lb (2,650 kg) |
PTO
| Item | Specification |
|---|---|
| Rear PTO type | 540 / 1000 / Ground |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 89.4 in (227 cm) |
| Weight | 6,185 – 6,604 lb |
| Front tire | 7.50-20 |
| Rear tire | 16.9-34 |
