Used Ford 8970 Tractor – High-Horsepower Genesis Series for Heavy-Duty Farming
EVERY FARM TRACTOR has exported used vehicles and agricultural tractors from Japan to more than 100 countries since 2006.
Among large row-crop tractors, the Ford 8970 remains a powerful and trusted model.
Therefore, it attracts farmers who search for a reliable Used Ford Tractor with high output and durability.
Overview
| Item | Details |
|---|---|
| Model | Ford 8970 |
| Production Years | 1993 – 2002 |
| Series | 70 Genesis Series |
| Manufacturer | Ford |
| Built In | Winnipeg, Manitoba, Canada |
| Tractor Type | Row-Crop Tractor |
| Drive Options | 2WD / 4WD |
As a result, the Ford 8970 suits large-scale farming and demanding field work.
Engine Specifications
| Item | Details |
|---|---|
| Engine Manufacturer | Ford |
| Engine Type | 6-cylinder diesel |
| Displacement | 7.5 L |
| Rated Engine Power | 240 hp (179.0 kW) |
Because of its large-displacement diesel engine, this tractor delivers strong torque and stable power under heavy load.
Transmission Options
| Item | Details |
|---|---|
| Main Transmission | 16-speed full power shift |
| Optional Transmission | 32-speed creeper |
Thus, operators can select precise speeds for field work and transport.
Power Performance
| Item | Output |
|---|---|
| Engine Power | 240 hp (179.0 kW) |
| PTO Power (claimed) | 210 hp (156.6 kW) |
| Drawbar Power (tested) | 189.5 hp (141.3 kW) |
| PTO Power (tested) | 224.6 hp (167.5 kW) |
Consequently, the Ford 8970 easily handles large implements and heavy PTO equipment.
Mechanical Features
| Item | Details |
|---|---|
| Drive System | Two- or four-wheel drive |
| Steering | Power steering |
| Brakes | Wet disc brakes |
| Cab | Enclosed cab with air-conditioning |
Moreover, the comfortable cab improves productivity during long working hours.
Fluid Capacities
| Item | Capacity |
|---|---|
| Fuel Tank | 110 gal / 416.4 L |
| Hydraulic System | 36.9 gal / 139.7 L |
| Front Hubs | 1.7 qts (each) |
| Front Differential | 13 qts |
Therefore, the tractor supports extended operation without frequent refueling.
Hydraulics
| Item | Details |
|---|---|
| Hydraulic Type | Closed center load sensing |
| System Pressure | 2750 psi / 189.6 bar |
| Rear Valves | 3 |
| Pump Flow | 24 gpm / 90.8 lpm |
| Total Flow | 31 gpm / 117.3 lpm |
| MegaFlow (optional) | 55 gpm / 208.2 lpm |
As a result, hydraulic response remains strong even with large implements.
Tractor Hitch
| Item | Details |
|---|---|
| Rear Hitch Type | Type III |
| Rear Lift Capacity | 15,000 lbs / 6,804 kg |
Thus, the Ford 8970 supports heavy rear-mounted equipment with confidence.
Power Take-Off (PTO)
| Item | Details |
|---|---|
| PTO Type | Independent |
| PTO Clutch | Electro-hydraulic wet disc |
| PTO Speed | 1000 rpm |
| Engine RPM @ PTO | 1000 @ 1903 rpm |
Therefore, the PTO delivers stable power for large agricultural machines.
Dimensions & Tires
| Item | Details |
|---|---|
| Wheelbase | 118.3 in / 300 cm |
| Wheelbase (SuperSteer) | 122.6 in / 311 cm |
| Operating Weight | 16,950 – 19,350 lbs |
| Front Tire | 14L-16.1 |
| Rear Tire | 18.4R42 |
Consequently, the wide stance improves traction and field stability.
Electrical System
| Item | Details |
|---|---|
| Ground | Negative |
| Charging System | Alternator |
| Charging Output | 130 amps |
| Batteries | 2 |
| Battery CCA | 950 |
| Battery Voltage | 12 V |
Thus, electrical performance remains reliable in cold and demanding conditions.
Why the Ford 8970 Is Still in Demand
The Used Ford 8970 Tractor continues to be popular because it offers:
-
High-output 7.5L diesel engine
-
Strong PTO and drawbar performance
-
Advanced power-shift transmission
-
Heavy-duty hydraulics with MegaFlow option
-
Comfortable cab for long working days
In addition, its Genesis Series design is known for durability.
Export Support by EVERY FARM TRACTOR
EVERY FARM TRACTOR can source and export the Ford 8970 to customers worldwide.
We support inspection, export documentation, and international shipping.
If you are looking for a powerful Used Ford Tractor for large-scale farming, the Ford 8970 is an excellent choice.
Please contact EVERY FARM TRACTOR for current availability and export details.
