Iseki TG5570 — Overview
The Iseki TG5570 is a high-output compact utility tractor from Iseki’s TG Series, produced from 2004 onward. With a 60 horsepower engine, standard 4WD, and a 12-speed power shuttle transmission, the TG5570 is designed for demanding farm operations that require strong PTO power and high hydraulic capacity—while keeping a compact footprint.
This model is especially well suited for loader work, rotary tilling, heavy mowing, and PTO-driven implements, making it a popular choice for export buyers who need power without moving to a full-size utility tractor.
Quick Specifications
| Item | Specification |
|---|---|
| Model | Iseki TG5570 |
| Series | TG Series |
| Type | Compact Utility Tractor |
| Production | 2004 – (unknown) |
| Manufacturer | Iseki |
| Drive | 4WD (standard) |
Engine
The TG5570 is powered by a proven Iseki 3.0-liter 4-cylinder diesel engine, delivering strong torque and stable output for continuous agricultural work.
| Engine Item | Detail |
|---|---|
| Engine manufacturer | Iseki |
| Engine type | Diesel |
| Cylinders | 4 |
| Displacement | 3.0 L |
| Rated engine power | 60 hp (44.7 kW) |
Power Output
| Item | Output |
|---|---|
| Engine power | 60 hp (44.7 kW) |
| PTO power (claimed) | 47 hp (35.0 kW) |
Transmission
The 12-speed power shuttle transmission allows smooth forward and reverse shifting, making the TG5570 ideal for loader and repetitive yard work.
| Item | Specification |
|---|---|
| Transmission type | Power shuttle |
| Gears | 12-speed |
| Steering | Power steering |
| Brakes | Wet disc brakes |
Hydraulics
The TG5570 features an open-center hydraulic system with high pump flow to support heavy rear implements and loaders.
| Item | Specification |
|---|---|
| Hydraulic type | Open center |
| Pump flow | 12.8 gpm (48.4 lpm) |
Hitch & PTO
| Item | Specification |
|---|---|
| Rear hitch type | Category II / I |
| Rear lift (at ends) | 3,924 lbs (1,779 kg) |
| Rear arms | Telescopic link ends |
| Rear PTO | Independent |
| Rear PTO speeds | 540 / 1000 rpm (1.375 in) |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 70.7 in (179 cm) |
| Operating weight | 4,090–4,442 lbs (approx.) |
| Front tires | 9.50-18 |
| Rear tires | 14.9-28 |
Operator Station & Mechanical Features
| Feature | Detail |
|---|---|
| Drive | Four-wheel drive |
| ROPS | Two-post folding ROPS |
| Cab | Optional cab with air-conditioning |
Why Choose the Iseki TG5570?
The Iseki TG5570 is highly valued by overseas buyers for its:
-
Strong 60HP 4-cylinder diesel engine
-
Standard 4WD with excellent traction
-
High hydraulic flow for loaders and heavy implements
-
540/1000 PTO compatibility for a wide range of equipment
