Ford 8630 Tractor (Brazil)
Production Years: 1992 – 1997
Series: 30 Superforça Series
Manufacturer: Ford (part of New Holland)
Built in: Curitiba, Brazil
Platform Note: Similar to Fiat 160-90
Overview
The Brazilian-built Ford 8630 belongs to the 30 Superforça Series, developed for heavy-duty agricultural work in demanding environments. Unlike the European/Belgian Ford 8630, this version uses a large-displacement Fiat 8.1L diesel engine and a robust 4WD drivetrain. Its strong PTO output, high lift capacity, and simple mechanical design make it popular across South America, Africa, and other export markets where durability and ease of maintenance are essential.
Series Map
| Model | Engine Power |
|---|---|
| Ford 8430 | 104.4 kW |
| Ford 8630 | 119.3 kW |
| Ford 8830 | 134.2 kW |
Engine
| Item | Specification |
|---|---|
| Engine model | Fiat diesel |
| Displacement | 8.1 L |
| Cylinders | 6-cylinder |
| Fuel type | Diesel |
| Cooling | Liquid-cooled |
| Aspiration | Naturally aspirated |
The Fiat 8.1L engine is well known for high torque and long service life, ideal for heavy tillage and large PTO implements.
Power
| Measurement | Output |
|---|---|
| Engine power | 160 hp / 119.3 kW |
| PTO power (claimed) | 140 hp / 104.4 kW |
Transmission
| Option | Details |
|---|---|
| Standard | 12-speed partially synchronized |
| Optional | 24-speed with creeper gears |
Mechanical Features
| Item | Specification |
|---|---|
| Drive | Four-wheel drive (4WD) |
| Differential lock | Hydraulic |
| Steering | Power steering |
| Brakes | Hydraulic wet disc |
| Operator station | Two-post ROPS |
| Cab | Optional, with air-conditioning |
Capacities
| System | Capacity |
|---|---|
| Fuel tank | 74 gal / 280.1 L |
| Hydraulic system | 15.7 gal / 59.4 L |
| Front axle oil | 13.6 qts / 12.9 L |
Hydraulics
| Item | Specification |
|---|---|
| Hydraulic capacity | 15.7 gal / 59.4 L |
| System pressure | 2503 psi / 172.6 bar |
| Pump flow | 14.5 gpm / 54.9 L/min |
Tractor Hitch
| Item | Specification |
|---|---|
| Rear hitch type | Category II |
| Hitch control | Position & draft control |
| Rear lift @ 24 in (610 mm) | 14,650 lb / 6,645 kg |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO type | Independent |
| PTO clutch | Hydraulic |
| Rear PTO speeds | 540 / 1000 rpm (1.375″) |
| Rated engine speed | 540 @ 1000 rpm |
Dimensions & Tires
| Item | Specification |
|---|---|
| Wheelbase | 113.6 in / 288 cm |
| Operating weight | 9,600 lb / 4,354 kg |
| Front tires | 14.9×28 |
| Rear tires | 18.4×38 |
Electrical System
| Item | Specification |
|---|---|
| Charging system | Alternator |
| Charging output | 65 amps |
| Battery voltage | 12 V |
| Battery capacity | 165 Ah |
Photos
Currently, no official photos of the Brazilian Ford 8630 are widely available online. This model is visually and mechanically similar to the Fiat 160-90, which shares the same platform and general layout.
Summary
The Ford 8630 (Brazil) is a true heavy-duty work tractor, combining a large 8.1L Fiat diesel engine with strong hydraulics and a simple, rugged design. Built for harsh conditions and long operating hours, it remains a valuable choice for farmers and contractors seeking reliable power with straightforward maintenance. Its continued demand in export markets reflects its reputation for strength, longevity, and practical engineering.
