Kubota GB155 Tractor Specifications and Model Guide
The Kubota GB155 is a sub-compact utility tractor produced from 2004 to 2006 as part of the Kubota GB Series.
With 4WD, a compact body and a powerful 0.9L diesel engine, the GB155 is ideal for customers who need more horsepower in a small tractor, especially in vegetable farms, orchards, vineyards and greenhouses.
This page explains the main specifications of the Kubota GB155, including engine displacement, transmission, PTO, and dimensions, so that overseas buyers can easily understand this Japanese used tractor.
Overview
| Item | Details |
|---|---|
| Model | Kubota GB155 |
| Tractor type | Sub-Compact Utility tractor |
| Series | Kubota GB Series |
| Production years | 2004 – 2006 |
| Manufacturer | Kubota Corporation (Japan) |
| Drive | 4WD (Four-wheel drive) |
| Steering | Manual steering (power steering optional) |
| Brakes | Mechanical wet disc brakes |
| ROPS | Two-post ROPS |
GB Series model map
| Series map | Engine power (approx.) |
|---|---|
| GB145 | 10.3 kW |
| GB155 | 11.0 kW |
| GB175 | 12.5 kW |
| GB150 (earlier model, 2002–2003) | 11.0 kW |
The GB155 is the 0.9L mid-range model in the later GB lineup, offering strong performance while keeping the same compact dimensions and excellent manoeuvrability.
Engine
The Kubota GB155 is powered by a 0.9L 3-cylinder Kubota diesel engine.
Compared with the smaller 0.7L GB models, this engine delivers more torque and power, which is very useful when working in heavier soil or using larger implements.
| Item | Details |
|---|---|
| Engine manufacturer | Kubota |
| Engine type | 4-stroke, liquid-cooled diesel |
| Cylinders | 3 cylinders |
| Displacement | 0.9 L class (approx. 900 cc) |
| Engine power | 14.8 hp (11.0 kW) |
| Aspiration | Naturally aspirated |
| Fuel type | Diesel |
| Fuel tank capacity | 3.4 gal (12.9 L) |
| Cooling system | Liquid-cooled |
| Starting system | Electric start |
This 3-cylinder diesel engine is known for:
-
Strong low-end torque for rotary tillers and soil preparation
-
Low fuel consumption suitable for daily farm work
-
High reliability as a Japanese-made Kubota power unit
Transmission
The GB155 uses a 6-speed gear transmission.
It is simple, durable and easy to maintain, with enough speed options for tillage, mowing, transport and manoeuvring.
| Item | Details |
|---|---|
| Transmission type | Gear drive |
| Number of gears | 6-speed gear (forward/reverse combination) |
| Clutch | Dry single-plate (typical for this class) |
| Drive system | 4WD (Four-wheel drive) |
This straightforward mechanical transmission is especially attractive for overseas users who prefer simple systems without complex electronics.
PTO (Power Take-Off) and Hitch
The Kubota GB155 is equipped with a rear PTO and a Category 0 three-point hitch, allowing it to use many small implements.
Rear PTO
| Item | Details |
|---|---|
| Rear PTO type | 540 / 1000 rpm |
| PTO shaft size | 1.375″ |
3-Point Hitch
| Item | Details |
|---|---|
| Rear hitch type | Category 0 |
| Hitch control | Position control |
With position control, the operator can set and maintain the implement working height precisely, which is very important for:
-
Uniform tillage depth
-
Clean and level mowing
-
Accurate ridging or bed forming
Dimensions & Tires
The GB155 shares the same 50-inch wheelbase as other GB models, but its slightly higher weight and different rear tire size give it good stability and traction.
| Item | Details |
|---|---|
| Wheelbase | 50 in (127 cm) |
| Weight | 1,246 lbs (565 kg) |
| Front tire | 5.00-12 |
| Rear tire | 8-18 |
This compact size is ideal for:
-
Narrow orchard rows
-
Greenhouses and small vegetable plots
-
Tight farmyards and garden paths
At the same time, its weight and 4WD system give the GB155 good grip on soft or wet ground, while still keeping soil compaction moderate.
Electrical System
| Item | Details |
|---|---|
| Ground | Electric (negative ground) |
| Battery | 12-volt battery |
The standard 12V electrical system powers the starter motor, lights and instruments, and replacement batteries are easy to find in most countries.
Photos
Currently, there are no official Kubota GB155 photos listed in the original data source.
On EVERY FARM TRACTOR’s website, we usually provide:
-
Front, side and rear exterior photos
-
Images of the operator’s area (seat, steering wheel, levers, pedals)
-
Engine bay and underbody views
-
Close-ups of tires, PTO shaft and three-point hitch
These detailed photos help overseas buyers check the real condition of each used tractor, such as rust, oil leaks, scratches, tire wear and any customized parts.
Kubota GB155 – Typical Applications
With its 0.9L diesel engine and 14.8HP output, the Kubota GB155 offers a strong performance level while remaining compact. It is ideal for:
-
Small and medium family farms
-
Commercial vegetable farms
-
Orchards and vineyards that need more PTO power in narrow spaces
-
Greenhouses and plastic tunnels
-
Garden and landscape maintenance, mowing and light trailer work
For overseas buyers, the GB155 provides:
-
Reliable Japanese build quality
-
Extra power compared with smaller GB models
-
Compact size that is easy to handle and easy to load into containers
-
Simple mechanical systems that are easy to service with basic tools
