The Iseki TG333 is a compact utility tractor from the Iseki TG Series, designed for professional farm and estate work.
With a 33 hp 1.5L 3-cylinder diesel engine, 16-speed shuttle transmission, and 4WD with rear differential lock, it is suitable for tillage, mowing, spraying, loader work and trailer towing on small and medium farms.
Below is an English specification sheet formatted for your EVERY FARM TRACTOR website.
Iseki TG333 – Overview
| Item | Specification |
|---|---|
| Manufacturer | Iseki |
| Model | TG333 |
| Series | TG Series |
| Tractor type | Compact utility tractor |
| Production years | ???? – 2004 (end of production 2004) |
| Engine model | Iseki 1.5L 3-cylinder diesel |
| Rated engine power | 33 hp (24.6 kW) |
| PTO power (claimed) | 31 hp (23.1 kW) |
| Drive configuration | Four-wheel drive (4WD) |
| Steering | Power steering |
| Rear diff lock | Standard (rear axle) |
| ROPS | Two-post ROPS |
| Typical uses | Rotary tiller, plough, mower, sprayer, loader, trailer work |
Engine – Iseki 1.5L 3-Cylinder Diesel
| Item | Specification |
|---|---|
| Engine type | 4-stroke, liquid-cooled diesel |
| Cylinders | 3 |
| Displacement | 1.5 L (approx. 1,500 cc) |
| Rated power | 33 hp (24.6 kW) |
| Fuel tank capacity | 34.8 L (9.2 US gal) |
| Aspiration | Naturally aspirated |
| Fuel system | Mechanical diesel injection (inline pump) |
| Cooling system | Liquid cooled |
| Starter | Electric, 12 V |
Engine description
The 1.5L Iseki diesel engine offers strong torque at low engine speed, excellent fuel economy and long service life.
It is well matched to heavier compact implements such as rotary tillers, flail mowers, sprayers and light front loaders.
Transmission & Driveline
| Item | Specification |
|---|---|
| Transmission type | 16-speed shuttle (gear drive) |
| Shuttle function | Forward / reverse shuttle lever for quick direction |
| Gears | 16 forward / 16 reverse (combined ranges) |
| Clutch | Dry type (two-stage typical for PTO engagement) |
| Drive | 4WD (mechanical front-wheel drive) |
| Rear differential lock | Pedal-operated, standard |
| Steering | Power steering |
| Brake type | Wet disc brakes |
Transmission notes
The shuttle transmission allows the operator to change direction quickly, which is ideal for loader and yard work.
The 16 gears give a wide range of field and transport speeds for precise operation with different implements.
Hydraulics & 3-Point Hitch
| Item | Specification |
|---|---|
| Hydraulic pump flow | 29.1 L/min (7.7 gpm) |
| 3-point hitch (rear) | Category I |
| Hitch control | Position control |
| Typical hydraulic uses | 3-point implements, rear tipping trailer, front loader (where fitted) |
Implement capability
With good hydraulic flow and a strong Category I hitch, the TG333 can operate a wide range of compact and mid-size farm implements for soil preparation, mowing, spraying and material handling.
PTO (Power Take-Off)
| Item | Specification |
|---|---|
| Rear PTO type | 540 rpm (standard) |
| PTO shaft size | 1.375″ (35 mm) 6-spline |
PTO usage examples
-
Rear rotary tiller
-
Flail or rotary mower
-
Sprayer or fertilizer spreader
-
Post-hole digger
-
Other 540 rpm PTO-driven implements
Dimensions, Weight & Tires
| Item | Specification |
|---|---|
| Wheelbase | 178 cm (70.1 in) |
| Operating weight | 1,529 kg (3,373 lb) |
| Front tires | 8–16 |
| Rear tires | 13.6–24 |
| Tractor size | Compact, stable 4WD chassis |
Size impression
The relatively long wheelbase and higher operating weight compared to smaller TG models give the TG333 excellent stability for towing, loader work and operation on uneven terrain, while it remains compact enough for orchards and narrow farm tracks.
Electrical System
| Item | Specification |
|---|---|
| System voltage | 12 V |
| Ground | Negative |
| Battery | 12 V (approx. 55 Ah typical) |
Model Summary for Overseas Buyers
The Iseki TG333 is a powerful compact 4WD tractor in the 33 hp class, featuring:
-
A durable 1.5L 3-cylinder diesel engine
-
16-speed shuttle transmission for fast forward/reverse work
-
Strong 4WD chassis with rear differential lock
-
Reliable hydraulics and Category I 3-point hitch
-
Standard 540 rpm PTO for worldwide implement compatibility
EVERY FARM TRACTOR has exported quality used Japanese tractors like the TG333 to more than 100 countries since 2006.
If you are interested in a used Iseki TG333 from Japan, please contact us for current stock details, photos and export quotations to your nearest port.
