The Iseki TF325 is a compact 4WD utility tractor in the 24 hp class, designed for small and medium farms, orchards, and landscaping work.
With a 1.4L 3-cylinder diesel engine, several transmission options and strong rear lift capacity, it is ideal for rotary tillers, mowers, loaders and trailers.
Below is an English specification sheet formatted for your EVERY FARM TRACTOR website.
Overview – Iseki TF325 Compact Utility Tractor
| Item | Specification |
|---|---|
| Manufacturer | Iseki |
| Model | TF325 |
| Tractor type | Compact utility tractor (4WD) |
| Years of production | From 2001 (exact end year not specified) |
| Engine model | Iseki 3-cylinder diesel (approx. 1.4 L) |
| Rated engine power | 24.2 hp (18.0 kW) |
| Drive configuration | 4×4 MFWD (four-wheel drive) |
| Steering | Power assist |
| Brake type | Differential mechanical wet disc |
| Typical uses | Tillage, rotary tiller, mower, loader, snow removal, trailer towing |
Engine – Iseki 1.4L 3-Cylinder Diesel
| Item | Specification |
|---|---|
| Engine type | 4-stroke diesel, liquid-cooled |
| Cylinders | 3 |
| Displacement | 1.4 L (approx. 85–90 cu in class) |
| Rated power | 24.2 hp (18.0 kW) |
| Fuel tank capacity | 23.1 L (6.1 US gal) |
| Aspiration | Natural |
| Fuel system | Diesel, mechanical injection |
| Cooling system | Liquid cooled |
| Starter type | Electric |
Model description:
This 1.4L 3-cylinder diesel engine is compact, fuel-efficient and designed for long life.
It provides enough torque at low rpm for rotary tilling and loader work while remaining quiet and economical for daily farm tasks.
Transmission & Driveline
The Iseki TF325 offers multiple transmission options, so buyers can choose the best setup for their work style.
| Item | Specification |
|---|---|
| Drive | 4WD (mechanical front-wheel drive) |
| Main transmissions | 9-speed unsynchronized / 12-speed unsynchronized / hydrostatic |
| 9-speed gearbox | 9 forward, 3 reverse, unsynchronized |
| 12-speed gearbox | 12 forward, 4 reverse, unsynchronized |
| Hydrostatic version | Infinite forward & reverse, multi-range HST |
| Clutch (gear models) | Dry, two-stage (for live PTO) |
| Steering | Power assist |
| Brakes | Differential mechanical wet disc |
Usage notes
-
9- or 12-speed gear models: Good for field work where you keep a constant working speed, for example ploughing or rotavating.
-
Hydrostatic model: Excellent for loader work, mowing around obstacles and precise manoeuvring, because speed and direction are controlled by pedal rather than gear shifting.
PTO, Hydraulics & 3-Point Hitch
| Item | Specification |
|---|---|
| Rear PTO type | Live PTO with two-stage clutch (gear models) |
| Rear PTO on HST models | Independent |
| Rear PTO speeds | 540 / 1000 rpm |
| Mid PTO type | Independent |
| Mid PTO speed | 2,000 rpm |
| 3-point hitch (rear) | Category I |
| Rear lift capacity (ends) | 899 kg (1,984 lb) at link ends |
| Hydraulic system type | Open centre, engine-driven pump (typical for this class) |
| Typical hydraulic uses | 3-point implements, rear tipping trailer, front loader (where equipped) |
Implement compatibility
With 540/1000 rpm rear PTO and 2,000 rpm mid PTO, plus almost 900 kg rear lift capacity, the TF325 can operate:
-
Rotary tillers and ploughs
-
Flail or finishing mowers (rear and mid-mount)
-
Snow blowers, sweepers and sprayers
-
Small front loaders and rear tipping trailers
This makes it a very versatile compact tractor for mixed farming and estate work.
Dimensions, Weight & Tires
| Item | Specification |
|---|---|
| Wheelbase | 1,646 mm (64.6 in) |
| Operating weight | 850–880 kg (1,874–1,940 lb), depending on spec |
| Front tires | 6–14 |
| Rear tires | 12.4–16 |
Size impression:
Thanks to its wheelbase of about 1.65 m and compact overall size, the TF325 is easy to handle in orchards, barns and tight farm yards, while the weight and 4WD layout give good traction for soil work.
Electrical System
| Item | Specification |
|---|---|
| System voltage | 12 V |
| Ground | Negative |
| Battery rating | 55 Ah |
| Charging | Engine-driven alternator |
| Starting | Electric starter |
Model Summary for Overseas Buyers
The Iseki TF325 is a 24.2 hp Japanese compact 4WD tractor with:
-
A durable 1.4L 3-cylinder diesel engine
-
Choice of 9-speed, 12-speed or hydrostatic transmission
-
Strong rear lift capacity of 899 kg and multiple PTO speeds
-
Compact dimensions suitable for orchards, greenhouses, small fields and municipal work
