Kubota GB130 Specifications & Model Guide
Overview
| Item | Details |
|---|---|
| Model | Kubota GB130 |
| Series | GB Series |
| Production Years | 2002 – 2003 |
| Tractor Type | Sub-Compact Utility Tractor |
| Manufacturer | Kubota (Japan) |
| Engine Power | 12.9 hp (9.6 kW) |
| Drive System | 4WD |
| ROPS | Two-post ROPS |
| Series Map | GB110 / GB130 / GB140 → GB135 (2004–2006) |
Model Description
The Kubota GB130 is a compact 4WD tractor in the GB Series, designed for small farms, orchards, gardens, and greenhouse operations.
With a 0.7L 3-cylinder diesel engine and a simple 6-speed gear transmission, it offers a good balance of power, fuel efficiency, and maneuverability. The GB130 is ideal for rotary tilling, mowing, light transport, and many daily farm tasks in narrow or tight working spaces.
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | 4-stroke, 3-cylinder diesel |
| Displacement | 0.7 L (approx. 700 cc) |
| Power Output | 12.9 hp (9.6 kW) |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 3.4 gal (12.9 L) |
| Cooling System | Liquid-cooled |
| Cylinders | 3 |
Engine Notes
The 0.7L Kubota diesel engine provides smooth low-end torque and very good fuel economy.
It is designed for reliable, long-hour operation with low vibration, making it suitable for repeated tillage and mowing work on small fields and orchards.
Transmission
| Specification | Details |
|---|---|
| Transmission Type | 6-speed gear transmission |
| Gears | 6 forward (plus reverse) |
| Drive | Mechanical 4WD |
| Steering | Manual steering |
| Brakes | Mechanical wet disc brakes |
Transmission Notes
The simple 6-speed gearbox keeps the GB130 easy to operate and maintain.
Combined with 4WD and wet disc brakes, it offers good traction and safe braking on soft or uneven ground, even with small implements attached.
PTO & Hitch
| Specification | Details |
|---|---|
| Rear Hitch Type | Category 0 |
| Hitch Control | Position control |
| Rear PTO Type | 540 / 1000 rpm (1.375″ spline) |
PTO & Hitch Notes
With a Category 0 three-point hitch and dual PTO speeds, the Kubota GB130 can drive many compact implements such as rotary tillers, small mowers, sprayers, and spreaders, making it highly versatile for small-scale professional users.
Dimensions & Tires
| Specification | Details |
|---|---|
| Wheelbase | 50 in (127 cm) |
| Operating Weight | 1,113 lbs (504 kg) |
| Front Tire | 4.00-12 |
| Rear Tire | 7-16 |
Dimension Notes
The compact wheelbase and moderate weight help the GB130 turn sharply and move easily in restricted areas such as orchards, vineyards, and greenhouses where larger tractors cannot enter.
Electrical
| Specification | Details |
|---|---|
| Ground | Negative (electric ground) |
| Battery Voltage | 12 V |
Photos
| Kubota GB130 | Description |
|---|---|
| No catalog photo available | Sub-compact 4WD tractor suited for orchards, gardens, and small farm work |
