Kubota GB110 Specifications & Model Guide
Overview
| Item | Details |
|---|---|
| Model | Kubota GB110 |
| Series | GB Series |
| Production Years | 2002 – 2003 |
| Tractor Type | Sub-Compact Utility Tractor |
| Manufacturer | Kubota (Japan) |
| Engine Power | 10.3 hp (7.7 kW) |
| Drive System | 4WD |
| ROPS | Two-post ROPS (folding type) |
| Series Map | GB110 → GB115 / GB130 |
Model Description
The Kubota GB110 is a very compact sub-utility tractor designed for small gardens, hobby farms, orchards, and greenhouse work.
With a lightweight body and 4WD traction, the GB110 is perfect for narrow paths, tight corners, and delicate soil conditions. Its simple 6-speed gear transmission and economical diesel engine make it a practical choice for users who need a basic but reliable machine for light tillage, mowing, and general maintenance tasks.
Engine
| Specification | Details |
|---|---|
| Engine Manufacturer | Kubota |
| Engine Type | 4-stroke, 2-cylinder diesel |
| Displacement | 0.5 L (approx. 500 cc) |
| Power Output | 10.3 hp (7.7 kW) |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 3.4 gal (12.9 L) |
| Cooling System | Liquid-cooled |
| Cylinders | 2 |
Engine Notes
The 0.5L 2-cylinder Kubota diesel engine is compact, quiet, and fuel efficient.
It is designed for low-speed, light-duty farm work, providing enough torque for small rotary tillers, mowers, and other compact implements while keeping running costs very low.
Transmission
| Specification | Details |
|---|---|
| Transmission Type | 6-speed gear transmission |
| Gears | 6 forward (plus reverse) |
| Drive | Mechanical 4WD |
| Steering | Manual steering |
| Brakes | Mechanical wet disc brakes |
Transmission Notes
The simple 6-speed gearbox is easy to operate and maintain.
Combined with 4WD and wet disc brakes, the GB110 offers stable performance on soft ground and slopes, even with small implements attached.
PTO & Hitch
| Specification | Details |
|---|---|
| Rear Hitch Type | Category 0 |
| Hitch Control | Position control |
| Rear PTO Type | 540 / 1000 rpm (1.375″ spline) |
PTO & Hitch Notes
Category 0 three-point hitch and dual PTO speeds allow the GB110 to work with many compact implements such as mini rotary tillers, small mowers, sprayers, and spreaders, making it very flexible for small-scale farming.
Dimensions & Tires
| Specification | Details |
|---|---|
| Wheelbase | 47.2 in (119 cm) |
| Operating Weight | 1,058 lbs (479 kg) |
| Front Tire | 4.00-10 |
| Rear Tire | 7-14 |
Dimension Notes
Thanks to its short wheelbase and low weight, the Kubota GB110 can turn sharply and operate safely in very limited spaces, such as small orchards, greenhouses, and residential gardens.
Electrical
| Specification | Details |
|---|---|
| Ground | Negative (electric ground) |
| Battery Voltage | 12 V |
Photos
| Kubota GB110 | Description |
|---|---|
| No catalog photo available | Sub-compact 4WD tractor ideal for gardens, greenhouses, and light farm work |
