Ford 7830 Overview
The Ford 7830 is a high-powered utility tractor produced from 1992 to 1997 as part of the 30 Superforça Series.
Built in Curitiba, Brazil by Ford (a part of New Holland), this model was designed for heavy-duty farm work, tillage, and large implements in demanding field conditions.
With a 112 hp engine, four-wheel drive, and strong drivetrain components, the Ford 7830 is well suited for medium and large farms that need a reliable, simple, and powerful tractor.
Overview Table
| Item | Details |
|---|---|
| Model | Ford 7830 |
| Series | 30 Superforça Series |
| Tractor Type | Utility tractor |
| Production Years | 1992–1997 |
| Manufacturer | Ford (a part of New Holland) |
| Factory | Curitiba, Brazil |
| Drive | 4WD (four-wheel drive) |
| Steering | Power steering |
| Brakes | Wet disc brakes |
| ROPS | Two-post ROPS |
Engine
The Ford 7830 uses a large-displacement 6-cylinder engine, designed for high torque and long service life.
Engine Specifications
| Item | Specification |
|---|---|
| Engine Manufacturer | Ford |
| Engine Type | 4-stroke, 6-cylinder diesel |
| Displacement | 6.6L |
| Engine Power | 112 hp (83.5 kW) |
| Aspiration | Naturally aspirated (typical for this class) |
| Cooling | Liquid-cooled |
Engine Description
The 6.6L Ford 6-cylinder diesel provides strong low-end torque and smooth power delivery, ideal for heavy draft work, plowing, deep cultivation, and pulling large trailers.
Its simple mechanical design makes servicing easier in export markets where electronic diagnostic tools may not always be available.
Transmission
The Ford 7830 is equipped with a 16-speed transmission, giving the operator plenty of gear choices for different tasks and field conditions.
Transmission Specifications
| Item | Specification |
|---|---|
| Transmission Type | Mechanical gearbox |
| Number of Speeds | 16-speed |
| Configuration | Multiple forward and reverse ranges for field and road work |
| Clutch | Dry clutch (typical for this class) |
This transmission setup allows precise control of speed for tillage, planting, spraying, and transport.
Hydraulics
The hydraulic system is designed to be simple and reliable, using an open-center layout.
| Item | Specification |
|---|---|
| Hydraulic Type | Open center |
| Pump Flow | 9.2 gpm (34.8 L/min) |
| Valves | — (not specified, typically 1–2 auxiliary valves) |
The flow rate is sufficient for common 3-point implements and basic hydraulic attachments.
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category II |
| Hitch Control | Position and draft control (typical for utility tractors in this class) |
This allows the Ford 7830 to work with a wide range of implements such as plows, harrows, cultivators, planters, and heavy mowers.
Power Take-off (PTO)
| Item | Specification |
|---|---|
| Rear PTO | Independent |
| PTO Type | 540 rpm |
The independent PTO makes it easy to engage or disengage power to implements like mowers, balers, and sprayers without stopping the tractor.
Dimensions & Tires
The original reference does not list the detailed dimensions and tire sizes, but you can still present a basic section like this on your website and fill in actual data later if you measure an in-stock unit.
| Item | Specification |
|---|---|
| Wheelbase | — (data not specified) |
| Operating Weight | — (data not specified) |
| Front Tires | Typical agricultural front tires for 4WD utility class |
| Rear Tires | Typical large rear agricultural tires for 112HP tractor |
Photos
No official photo was provided in the reference, but for your EVERY FARM TRACTOR website, we recommend:
-
Side profile of Ford 7830 in a field
-
Rear view showing 3-point hitch and PTO
-
Operator station and dashboard
-
4WD front axle and tires
When you have actual stock, you can add these images under a “Photos” section.
Model Summary
The Ford 7830 is a strong and straightforward 112HP utility tractor from Ford’s Brazilian-built 30 Superforça Series.
With its 6.6L 6-cylinder diesel engine, 16-speed transmission, 4WD, and open-center hydraulics, it offers a good balance of power, durability, and ease of maintenance.
