Ford 7810S Overview
The Ford 7810S is a 100-horsepower utility tractor produced from 1994 to 1998 as part of the 10S Series.
Built in Queretaro, Mexico, this model followed the successful Ford 7810 row-crop tractor but was redesigned for utility work with simplified hydraulics, durable drivetrain options, and excellent serviceability.
With its 6.6L 6-cylinder diesel engine, multiple transmission configurations, and dependable mechanical layout, the Ford 7810S remains popular among farmers who need a robust and easy-to-maintain tractor capable of heavy pulling and general-purpose agricultural tasks.
The original price was $33,000 in 1998, making it a high-value choice in its class.
Overview Table
| Item | Details |
|---|---|
| Model | Ford 7810S |
| Series | 10S Series |
| Tractor Type | Utility tractor |
| Years Produced | 1994–1998 |
| Manufacturer | Ford |
| Factory | Queretaro, Mexico |
| Original Price | $33,000 (1998) |
| Drive Options | 2WD or 4WD |
| Steering | Hydrostatic power steering |
| Brakes | Wet disc brakes |
| ROPS | Two-post ROPS |
Engine
| Item | Specification |
|---|---|
| Engine Model | Ford diesel |
| Engine Type | 6-cylinder diesel |
| Displacement | 6.6L |
| Engine Power | 100 hp (74.6 kW) |
| PTO Power (claimed) | 90 hp (67.1 kW) |
| Fuel Capacity | 21.5 gal (81.4 L) |
| Auxiliary Tank | 13.2 gal (50.0 L) |
| Cooling | Liquid-cooled |
Engine Description
The Ford 6.6L diesel engine delivers strong torque, smooth performance, and long engine life.
Its large displacement supports heavy pulling implements, PTO equipment, and long working hours, making it ideal for general farm operations.
Transmission
| Transmission Type | Speeds | Notes |
|---|---|---|
| Unsynchronized Gear | 8-speed | Simple, durable, low maintenance |
| Two-Speed Power Shift | 16-speed | Allows shifting under load, better for loader and field work |
These options provide flexibility for a wide range of tasks from tillage to transport.
Hydraulics
| Item | Specification |
|---|---|
| System Type | Gear pump |
| Pressure | 2500 psi (172.4 bar) |
| Pump Flow | 9.7 gpm (36.7 L/min) |
| Rear Valves | 2 |
The hydraulic system is simple, reliable, and easy to maintain—ideal in export markets.
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category II |
| Rear Lift Capacity | 4,040 lbs (1,832 kg) |
| Hitch Control | Mechanical control |
Power Take-Off (PTO)
| Item | Specification |
|---|---|
| PTO Type | Independent |
| PTO Speed | 540 / 1000 rpm |
Dimensions & Tires
| Item | 2WD | 4WD |
|---|---|---|
| Wheelbase | 97.8 in (248 cm) | 99.1 in (251 cm) |
| Item | Specification |
|---|---|
| Weight | 7,721–8,361 lbs |
| Front Tire | 10.00-16 |
| Rear Tire | 18.4-34 |
Photos
Recommended photo composition for EVERY FARM TRACTOR website:
-
Side profile of Ford 7810S
-
Operator station (ROPS) view
-
6.6L engine close-up
-
Rear PTO and hitch assembly
-
4WD front axle and steering system
(Actual images can be added when available.)
Summary
The Ford 7810S is a durable and powerful utility tractor designed for farmers seeking reliability, simplicity, and strong pulling performance.
Its 100-horsepower engine, proven drivetrain, and robust construction make it suitable for field preparation, loading operations, mowing, hauling, and other agricultural tasks.
