Ford 7810 Overview
The Ford 7810 is a powerful 105-horsepower row-crop tractor produced between 1988 and 1991.
As one of Ford’s higher-horsepower models of the late 1980s, the 7810 was built for demanding field operations, tillage, transport, and heavy 3-point implement work.
With its 6.6L 6-cylinder diesel engine, advanced transmission options, strong hydraulic flow, and durable chassis, the Ford 7810 remains a popular choice in export markets—especially where reliability and mechanical simplicity are essential.
The tractor’s original price was $32,000 in 1990, offering exceptional value for a machine of this size and performance.
Overview Table
| Item | Details |
|---|---|
| Model | Ford 7810 |
| Series | Row-crop tractor |
| Production Years | 1988–1991 |
| Manufacturer | Ford |
| Tractor Type | Row-crop |
| Original Price | $32,000 (1990) |
| Drive Options | 2WD or 4WD |
| Final Drives | Inboard planetary |
| Differential Lock | Mechanical rear |
| Cab | Optional (ROPS standard) |
Engine
| Item | Specification |
|---|---|
| Engine Model | Ford diesel |
| Engine Type | 6-cylinder diesel |
| Displacement | 6.6L |
| Gross Engine Power | 105 hp (78.3 kW) |
| Net Engine Power | 100 hp (74.6 kW) |
| PTO Power (claimed) | 86 hp (64.1 kW) |
| Fuel Tank Capacity | 35 gal (132.5 L) |
| Cooling | Liquid-cooled |
Engine Description
The Ford 6.6-liter diesel engine is known for high torque, excellent durability, and smooth operation.
Its large displacement provides strong pulling power, making the 7810 suitable for heavy tillage, baling, mowing, trailer hauling, and other intensive agricultural tasks.
Transmission
Two transmission configurations were available:
| Transmission Type | Speeds | Notes |
|---|---|---|
| Standard Gear | 8-speed | Simple and durable |
| Power Shift | 16-speed | Better control for loader and field applications |
Both systems offer reliable performance with minimal electronic components, making the tractor easy to maintain globally.
Power Ratings
| Rating | Power |
|---|---|
| Engine (gross) | 105 hp (78.3 kW) |
| Engine (net) | 100 hp (74.6 kW) |
| PTO (claimed) | 86 hp (64.1 kW) |
The 7810 provides more than enough power for heavy implements and high-demand farming operations.
Hydraulics
| Item | Specification |
|---|---|
| System Type | Open center |
| Valves | 2 to 4 |
| Pump Flow | 18.2 gpm (68.9 L/min) |
This hydraulic output is strong for its class and supports heavy 3-point implements as well as loader attachments.
Tractor Hitch
| Item | Specification |
|---|---|
| Rear Hitch Type | Category II |
| Rear Lift Capacity | 4,020 lbs (1,823 kg) |
| PTO Speeds | 540 / 1000 |
| PTO Type | Independent |
| PTO Shaft | 1.375-inch |
| PTO RPM | 540 @ 1900 rpm / 1000 @ 2060 rpm |
Dimensions & Tires
| Item | 2WD | 4WD |
|---|---|---|
| Wheelbase | 99.1 in (251 cm) | 99.2 in (251 cm) |
| Item | Specification |
|---|---|
| Weight | 8,228–9,460 lbs |
| Front Tire | 10.00-16 |
| Rear Tire (2WD) | 16.9-38 |
Heavy-duty 4WD versions are especially valued in hilly or high-traction environments.
Photos
Suggested images for the EVERY FARM TRACTOR website:
-
Side profile of Ford 7810 Series II
-
Cab and open-station versions
-
Engine and rear hydraulic arms close-up
-
PTO shaft and Category II hitch
-
4WD axle and front tires
(Actual photos may be added as soon as available.)
Summary
The Ford 7810 is a strong, reliable, and high-capacity row-crop tractor designed for demanding agricultural operations.
With its 105-hp engine, solid mechanical construction, and high hydraulic flow, it remains a highly valued machine in global export markets.
