Iseki TF173 Tractor Specifications and Detailed Overview
The Iseki TF173 is a compact utility tractor designed for light farming, landscaping, orchard work, and general-purpose tasks.
Powered by a reliable Iseki 1.0L 3-cylinder diesel engine, the TF173 delivers outstanding efficiency and durability—ideal for global users seeking a dependable Japanese compact tractor.
With selectable 4WD, multiple PTO speeds, and a strong structural design with folding ROPS, the TF173 offers excellent versatility and operational safety for a wide range of agricultural environments.
📌 Overview
| Item | Details |
|---|---|
| Model | Iseki TF173 |
| Series | TF Series |
| Tractor Type | Compact Utility Tractor |
| Engine Power | 17.3 hp (12.9 kW) |
| PTO Power | 15.6 hp (11.6 kW) |
| Drive System | 4WD |
| ROPS | Two-post folding ROPS |
| Manufacturer | Iseki (Japan) |
| Production | — |
📌 Engine
| Specification | Details |
|---|---|
| Engine Model | Iseki 1.0L 3-cylinder diesel |
| Displacement | approx. 1.0 L |
| Power | 17.3 hp (12.9 kW) |
| Fuel Tank Capacity | 4.8 gal / 18.2 L |
| Cooling System | Liquid-cooled |
| Fuel Type | Diesel |
| Notes | The lightweight 1.0L engine is known for smooth operation, low vibration, and excellent fuel economy. |
📌 Transmission
| Specification | Details |
|---|---|
| Type | 6-speed manual / 6-speed shuttle |
| Forward Gears | 6 |
| Reverse Gears | 2 (manual) / shuttle reverse |
| PTO Speeds | 540 rpm |
| PTO RPM at Engine Speed | 522 / 783 / 1183 @ 2500 rpm |
📌 Dimensions
| Item | Measurement |
|---|---|
| Wheelbase | 54.9 in / 139 cm |
| Weight | 1649 lbs / 747 kg |
| Front Tire | 6-12 |
| Rear Tire | 8.3-20 |
📌 Mechanical Features
| Feature | Details |
|---|---|
| Drive | 4WD |
| Steering | Manual / Power (varies by configuration) |
| Brakes | Mechanical |
| ROPS | Folding (2-post) |
📌 PTO & Hitch
| Item | Details |
|---|---|
| PTO Type | Rear 540 rpm |
| Category | Type 0 |
| PTO RPM Options | 522 / 783 / 1183 rpm @ 2500 engine rpm |
📌 Electrical
| Item | Details |
|---|---|
| Ground | Negative |
| Battery | 12V |
📸 Photos
Currently no photos are available for the Iseki TF173.
If you wish to add a photo, please contact us.
